RYLE ROMAN TUB FAUCET
INSTALLATION INSTRUCTIONS
Before installing, read entire installation instructions. Observe all local building and safety codes.
Unpack and inspect the product for any shipping damages. If you find damages, do not install. Contact Customer
Service at 1-866-855-2284. If you need assistance or have questions while installing your faucet, contact Customer
Service.
We recommend consulting a professional if you are unfamiliar with installing bathroom fixtures. Signature Hardware
accepts no liability for any damage to the floor, walls, plumbing or for personal injury during installation.

TOOLS AND MATERIALS:

Screwdriver

INSTALLATION

1. Thread the faucet body through the center mounting hole.
2. Insert the handle bodies up through the mounting holes. Secure the handle assemblies to the handle bodies
3. Attach the Hand shower to the mounting service.
4. Thread the mounting hardware and brass T onto the faucet body and tighten to secure.
Ø35
Ryle Roman Tub Faucet Installation Instructions
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RYLE ROMAN TUB FAUCET and is the answer not in the manual?

Questions and answers

Related Manuals for Signature Hardware RYLE ROMAN TUB FAUCET

Summary of Contents for Signature Hardware RYLE ROMAN TUB FAUCET

  • Page 1 Service at 1-866-855-2284. If you need assistance or have questions while installing your faucet, contact Customer Service. We recommend consulting a professional if you are unfamiliar with installing bathroom fixtures. Signature Hardware accepts no liability for any damage to the floor, walls, plumbing or for personal injury during installation.
  • Page 2 (no water should be leaking) and that the hot and cold supplies are working correctly. Turn the faucet on and allow the water to flow through the spout for approximately 60 seconds. Divert the water to the hand shower and allow the water to flow through the hose for an additional 60 seconds. Ryle Roman Tub Faucet Installation Instructions...
  • Page 3 40.3930.2.4302 SD10101000700C PW-3 M0404030 G0205 SD10912000900 G0406 OXQ2802 G0204 SD10112000500-1 SD10112000800 SD10112000400 M0205008 SD10112000500-2 SD10112000500-3 SD10112000500-4 SD10112000500-5 SD10112000500-6 SD10112000500-7 M110404 SD10101000800 SD10910000500 OXQ4803 OXQ2102 SD10112000500-8 SD10112000500-9 SD10112000500-10 SD10112000500-11 SD10910000100 M0404030 SD10110000300 SD10910000400 SD10910000500 OXQ4603 Ryle Roman Tub Faucet Installation Instructions...
