RYLE 4-WAY THERMOSTATIC VALVE
INSTALLATION INSTRUCTIONS
Before you begin, read the installation instructions below. Observe all local building and safety codes.
Unpack and inspect the product for any shipping damages. If you find damages, do not install. Contact Customer
Service at 1.866.855.2284. If you need assistance or have questions while installing your diverter valve, contact
Customer Service.
We recommend consulting a professional if you are unfamiliar with installing bathroom fixtures, and plumbing.
Signature Hardware accepts no liability for any damage to the plumbing or wall, or for personal injury during
installation.
TOOLS AND MATERIALS:
Screwdriver
INSTALLATION
1. Install the valve body. Wrap the threaded portion
of the joints in Teflon tape and connect the water
inlet and outlet.
3. When the finished wall is complete, remove
the protective covers.
2. Put the protective covers on the valve body
and finish the shower wall.
4. Install the escutcheon, and handle. Tighten the set
screw with an Allen wrench to secure.
Ryle 4-way Thermostatic Valve Installation Instructions
1
