- Page 1 Nano Roll Installation Instructions 110v AC - 485 INSTALLERS: Please leave this manual with the owner. Doc. # 400032...
-
Page 3: Terminal Blocks
PARTS LIST - NANO ROLL - 110v AC - 485 Shades Terminal Blocks 375 Roll 475 Roll Please note all the Node IDs on your Shade motors. See the last page on these instructions. Wall Brackets (375 / 475) + End Caps Screws included Motor Side Idler Side... - Page 4 PARTS LIST - NANO ROLL - 110v AC- 485 Leveling Shims (optional) ADDITIONAL ACCESSORIES - NANO ROLL - 110v AC- 485 5/16” Magnetic Driver Set Screw Hex Tool (1/8”) Note: For more information about these tools and their use, please call Tech Support at 512.832.6939 Opt.
- Page 5 SPACER BLOCKS AND LEVELING SHIMS (OPTIONAL) Spacer Blocks - used to clear an obstruction in the fabric path. Connect spacer blocks to shade brackets before installation. Note: Do not use more than 4 spacer blocks per bracket. Leveling Shims - used if the window frame is out of level. Connect to shade brackets before installation Note: Do not use more than 2 leveling shims per bracket.
- Page 6 INSTALLATION - 110v AC - 485 (375 / 475 SERIES) Before installing the shades, verify whether the shade was ordered as standard roll or reverse roll. Though illustrations in this manual show standard roll shades, the installation for reverse roll shades is the same. 1.
- Page 7 INSTALLATION - 110v AC - 485 (375 / 475 SERIES) 3. Install wall bracket/end cap assembly with the supplied screws for Ceiling Mount for Wall Mount Idler side Motor side 4. Measure bracket to bracket width and verify it matches the ordered width. Adjust accordingly. Brackets must be level before the shade is installed! Installation - Nano Roll - 110v AC - 485 - 375 / 475...
- Page 8 INSTALLATION - 110v AC - 485 (375 / 475 SERIES) 5. Remove both end caps Motor End cap 1/8” hex tool Idler End cap Pg 6 Installation - Nano Roll - 110v AC - 485 - 375 / 475...
- Page 9 INSTALLATION - 110v AC - 485 (375 / 475 SERIES) 6. Push power cable into pre-wire hole and connect shade and pre-wire, snap terminal block into spring clip. Data Cable Power Cable Note: Motor cable is not plenum rated. Terminate accordingly. 7.
- Page 10 INSTALLATION - 110v AC - 485 (375 / 475 SERIES) 8. Then put idler end cap over idler and snap into place. There will be an audible click. Pg 8 Installation - Nano Roll - 110v AC - 485 - 375 / 475...
- Page 11 INSTALLATION - 110v AC - 485 (375 / 475 SERIES) 9. Replace and fasten motor end cap 1/8” Hex tool Pg 9 Installation - Nano Roll - 110v AC - 485 - 375 / 475...
- Page 12 PROGRAMMING 485 RS485 shades are programmed using the Screen Innovations SIFI via the web interface. This programming can be done with a Windows or Mac computer either over LAN or wired directly to SIFI. The following instructions are for a Windows computer, but the steps for programming on a Mac are very similar.
-
Page 13: Troubleshooting 485
TROUBLESHOOTING TROUBLESHOOTING 485 Tech Support: 512.832.6939 Problem Possible Cause Action to Take Ensure that 24V hardwired motors have at least Shade won’t Motor is not powered. 20VDC and that the polarity is correct. operate. Check the wire pinouts and termination. Look for Incorrect or poor cable broken, loose, or damaged wires. - Page 14 Pg 12...
- Page 15 NODE IDS Please keep a note of all the Node IDs on your shade motors. OR for larger shade orders, refer to your Sales Order document for the list. Room Shade 1 Shade 2 Shade 3 Shade 4 Shade 5 Shade 6 Room Shade 1...
- Page 16 Screen Innovations 9715-B Burnet Rd, Suite 400 Austin, TX 78758 512.832.6939 www.screeninnovations.com 400032 v. 1.2 15 October 2019...
