- Page 1 Nano Roll Installation Instructions WIREFREE - ZIGBEE INSTALLERS: Please leave this manual with the owner. Doc. # 400089...
-
Page 3: Table Of Contents
Table of Contents PARTS LIST - NANO ROLL - 275 - WIREFREE � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 2 PARTS LIST - NANO ROLL - 375 - WIREFREE �... -
Page 4: Parts List - Nano Roll - 275 - Wirefree
PARTS LIST - NANO ROLL - 275 - WIREFREE Shades (275 Roll) Charger Please note all the QR CODES on your Shade motors. See the last page on these instructions. Spacer Blocks Leveling Shims Wall Brackets (optional) (optional) Ceiling Brackets Situo Remotes (Optional) Screws Included... -
Page 5: Parts List - Nano Roll - 375 - Wirefree
PARTS LIST - NANO ROLL - 375 - WIREFREE Charger Shades (375 Roll) Please note all the QR CODES on your Shade motors. See the last page on these instructions. Wall Brackets (375) Spacer Blocks Leveling Shims (optional) (optional) Motor Side Situo Remotes (Optional) Idler Side... -
Page 6: Spacer Blocks And Leveling Shims
SPACER BLOCKS AND LEVELING SHIMS (OPTIONAL) Spacer Blocks - used to clear an obstruction in the fabric path. Connect spacer blocks to shade brackets before installation Note: Do not use more than 4 Spacer blocks per bracket. Leveling Shims - used if the window frame is out of level. Connect to shade brackets before installation Note: do not use more than 2 leveling shims per bracket. -
Page 7: Installation - Nano Roll - 275 - Wirefree
INSTALLATION - NANO ROLL - 275 - WIREFREE 1. Install the wall bracket / end cap assemblies with the supplied screws for Ceiling Mount for Wall Mount Motor Idler side side Use 1/4” magnetic driver (incl.) 2. Measure the bracket to bracket width and verify it matches the ordered width. Adjust accordingly Brackets must be level before the shade is installed! Installation - Nano Roll - 275 - Wirefree... - Page 8 INSTALLATION - NANO ROLL - 275 - WIREFREE 3. Remove the idler end cap with flat bladed screw driver 4. Insert motor side completely. NOTE: When installing, the shade should be at the upper limit. Installation - Nano Roll - 275 - Wirefree...
- Page 9 INSTALLATION - NANO ROLL - 275 - WIREFREE 5. Then, while supporting motor side, put idler end cap over the idler and snap into place. There will be an audible click. Installation - Nano Roll - 275 - Wirefree...
-
Page 10: Installation - Nano Roll - 375 - Wirefree
INSTALLATION - NANO ROLL - 375 - WIREFREE NOTE: If mounting to a wall, remove the ceiling flange from motor and idler brackets. 1. Install wall bracket/end cap assembly with the supplied screws for Ceiling Mount for Wall Mount Motor Idler side side... - Page 11 INSTALLATION - NANO ROLL - 375 - WIREFREE 2. Measure bracket to bracket width and verify it matches the ordered width. Adjust accordingly. Brackets must be level before the shade is installed! Installation - Nano Roll - 375 - Wirefree...
- Page 12 INSTALLATION - NANO ROLL - 375 - WIREFREE 3. Remove both end caps 1/16” hex tool Motor End cap Idler End cap Installation - Nano Roll - 375 - Wirefree...
- Page 13 INSTALLATION - NANO ROLL - 375 - WIREFREE 4. Align and insert the motor side. Antenna Magnetic Connector 5. Make sure the motor head bracket is fully seated. Secure with cotter pin. Installation - Nano Roll - 375 - Wirefree...
- Page 14 INSTALLATION - NANO ROLL - 375 - WIREFREE 6. Put idler end cap over idler and snap into place. There will be an audible click. Installation - Nano Roll - 375 - Wirefree...
- Page 15 INSTALLATION - NANO ROLL - 375 - WIREFREE 7. Install magnetic connector into end cap and fasten with 0.050” hex tool (incl.) Magnet must be flush with end cap. 8. Install end cap and fasten with 0.125” hex tool (incl.). Route magnetic connector wire behind cotter pin and away from fabric roll.
-
Page 16: Programming Zigbee
PROGRAMMING - ZIGBEE PROGRAMMING STEPS (TaHoma/LinkPro Z must be plugged in and on the network) Step 1: Fine tune lower limit. Step 2: Assign shades to groups and remotes. Step 3: Pair devices and groups with remotes. The lower limit of every shade is preprogrammed to 1/2” from the bottom of the window. After installing each shade, follow these steps to adjust the lower limit: STEP 1 - Fine tuning lower limit : 1. -
Page 17: Troubleshooting Zigbee
TROUBLESHOOTING - ZIGBEE Tech Support: 512.832.6939 Problem Possible Cause Action to Take For Zigbee Check network connection to the internet, and ensure TaHoma LED is Red. No internet the TaHoma is properly connected via ethernet or connectivity. Wifi. Check the battery level of a motor via the TaHoma Shade won’t operate. - Page 18 NOTES: Pg 8 Notes...
- Page 19 QR CODES Please keep a note of all the Serial No.s on your shade motors. OR for larger shade orders, refer to your Sales Order document for the list. Room Shade 1 Shade 2 Shade 3 Shade 4 Shade 5 Shade 6 Room Shade 1...
- Page 20 Screen Innovations 9715-B Burnet Rd, Suite 400 Austin, TX 78758 512.832.6939 www.screeninnovations.com 400089 v. 1.3 19 June 2020...
