  • Page 1 Silvertel POE Ag5810 Evaluation Board User Manual Rev 1.0 – December 2019...

  • Page 2: Table Of Contents

    POEAg5810 Evaluation Board User Manual 1 Table of Contents Table of Contents Table of Figures Introduction 4.1 EvalAg5810 ......................2 Evaluation Board Description 5.1 Link settings ......................3 5.2 Input ........................3 5.3 Diode Bridge Selection ..................3 5.4 Input Signature ....................4 5.4.1 Powered from Phihong 12.5K Signature PSE 5.5 PSE Detect ......................

  • Page 3: Introduction

    The board is designed to handle 10/100/1000/10GBASE-T Ethernet data rates. 4.1 EvalAg5810 The EVALAG5810 evaluation board is fitted with SilverTel’s Ag5810 IEEE802.3bt PD module and can be used to extract power from an IEEE compliant PSE through its RJ45 connector J101.

  • Page 4: Link Settings

    POEAg5810 Evaluation Board User Manual 5.1 Link settings LK1 – Input power LED LK2 – Output adjust select LK3 & LK6 – Output configuration (Parallel “12V” or Series “24V”) LK4 – Output power LED LK7 – Signature Adjustment 5.2 Input The EVALAG5810 evaluation board can be powered from the EVALAg6800 evaluation board or any IEEE802.3bt PSE.

  • Page 5: Input Signature

    The Ag5810 provides a 25K signature required to be powered from an IEEE compliant PSE. The EvalAg5810 has been designed to be powered from an IEEE802.3bt PSE such as SilverTel’s Ag6800 PSE module. However the Ag5810 has also provisions for being powered from Legacy PSE’s such as PoH or Phihongs 12.5K signature PSE.

  • Page 6: Pd Output Selection

    POEAg5810 Evaluation Board User Manual 5.6 PD Output Selection Before using the EVALAg5810 evaluation board, it is important to setup the output configuration jumpers for the correct output voltage. The Ag5810 has two DC outputs that must be connected in parallel or in series. The outputs cannot be run independently so the EVALAg5810 board has output selector links LK3 and LK6.

  • Page 7: Output Adjustment

    10.55V up to 15V. The secondary output will track the adjusted primary output voltage. Voltage must not be adjusted to less than 10.5V or permanent damage may be caused. Contact Silvertel for further details The EVALAg5810 board has an adjust link LK2 and two resistors R2 (91K) and R4 (8K2) which allows the output to be adjusted to its maximum and minimum values.

  • Page 8: Typical Set-Up

    POEAg5810 Evaluation Board User Manual Typical Set-up 6.1 Power Supply Input Figure 2 shows the basic set up using SilverTel’s EVALAG6800 evaluation board along with the EVALAG5810 evaluation board with a power supply input to JP1. The equipment required: - ...
  • Page 9 J100 J100 T100 T100 J101 J101 749052050 749052050 R100 R100 R101 R101 R102 R102 R103 R103 R104 R104 R105 R105 R106 R106 R107 R107 C100 C100 C101 C101 C102 C102 C103 C103 C104 C104 C105 C105 C106 C106 C107 C107 10nF 100V 10nF 100V 10nF 100V...
  • Page 10 EVALAg5510 - Rev-2R 7th May 2017 Date ***'Strictly Private and Company Confidential*** Silver Description Value Qty: Package: Rating: Tol: Supplier Pt NO: Comments: Location: Part No. PD Module Ag5810 Custom Silver Telecom Part Protection Diode SMAJ58A Vishay, Diodes Inc, Wurth- 824 500 581, Zener Diode BZX384C30V SOD-323-2...
