Settings

Use element X under Mac OS X
Mac OS X does not need a driver. Please select the audio device as 'element Series'
in System Preferences.
Connect element X to mobile devices via USB port
Use Apple Lightening to USB Camera Kits to connect element X with iOS devices.
element X can be connected to an Android device with Micro USB or Type-C USB port
via the OTG cable， but it's not guaranteed to be compatible with all Android devices.
5. Settings
Repeat pressing the 'Menu' key to enter into configuration menu, then
press the knob to enter configuration items.
As shown:
There are 15 items in the configuration menu as follow:

5.1 Lineout Mode

Lineout mode can be set as,
0dB Fixed: 0dB gain , fixed
0dB ADJ: 0dB gain， attenuation adjustable （Default）
10dB ADJ: +10dB gain， attenuation adjustable
Connect to power amplifier including volume control, recommend to set as
'0dB Fixed'
Connect to active speakers, recommend to set as '0dB ADJ'
Connect to active speakers which has lower volume gain, recommend to set
as '+10dB ADJ'
13
Users Manual
Push knob enter settings
Settings
Lineout Mode
1
10dB ADJ
Line output max volume
Press "〇" button to confi rm
