Long-Range Exit-Side Lockout Kit
2226, 4045, and 4050 Directional Drill
Model No. 133-6314
Introduction
The exit-side lockout transmitter and receiver is
designed to remotely stop and lockout the user
controls of a directional drill.
Read this information carefully to learn how to operate
and maintain your machine properly and to avoid
injury and equipment damage. You are responsible
for operating the machine properly and safely.
You may contact Toro directly at www.Toro.com for
product and accessory information, help finding a
dealer, or to register your product.
This manual identifies potential hazards and has
safety messages identified by the safety alert symbol
(Figure
1), which signals a hazard that may cause
serious injury or death if you do not follow the
recommended precautions.
1. Safety alert symbol
This manual uses 2 words to highlight information.
Important calls attention to special mechanical
information and Note emphasizes general information
worthy of special attention.
This product complies with all relevant European
directives. For details, see the separate
product-specific Declaration of Conformity (DOC)
sheet.
This product may contain material that may be
hazardous to human health and the environment. In
compliance with EU Directive 2002/96/EC on Waste
Electrical and Electronic Equipment (WEEE):
Do not dispose of the product as unsorted
municipal waste.
This product should be recycled in accordance
with local regulations. Contact local authorities for
detailed information.
This product may be returnable to the distributor
for recycling. Contact your distributor/dealer for
details.
© 2018—The Toro® Company
8111 Lyndale Avenue South
Bloomington, MN 55420
Figure 1
Register at www.Toro.com.
FCC Statements
15.19 – Two Part Warning
This device complies with Part 15 of the FCC rules. Operation
is subject to the following two conditions:
(1) This device may not cause harmful interference and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
15.21 – Unauthorized Modification
NOTICE: The manufacturer is not responsible for any
unauthorized modifications to this equipment made by the user.
Such modifications could void the user's authority to operate
the equipment.
15.105(b) – Note:
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
g000502
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
Industry Canada Statement
This device complies with Canadian RSS-210.
The installer of this radio equipment must ensure that the
antenna is located or pointed such that it does not emit RF field
in excess of Health Canada limits for the general population;
consult Safety Code 6, obtainable from Health Canada's
website www.hc-sc.gc-ca/rpb.
This device complies with Industry Canada licence-exempt
RSS standard(s). Operation is subject to the following two
conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including interference
that may cause undesired operation of the device.
Original Instructions (EN)
Form No. 3407-663 Rev B
Operator's Manual
All Rights Reserved *3407-663* B
Printed in the USA.
