- Page 1 CUMB1 - Universal Mobile Base.fm Page 1 Thursday, March 28, 2013 12:34 PM UNIVERSAL MOBILE BASE MODEL NO: CUMB1 PART NO: 7630211 ASSEMBLY & OPERATING INSTRUCTIONS LS0313...
- Page 2 CUMB1 - Universal Mobile Base.fm Page 2 Thursday, March 28, 2013 12:34 PM INTRODUCTION Thank you for purchasing this CLARKE Universal Mobile Base. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service.
- Page 3 CUMB1 - Universal Mobile Base.fm Page 3 Thursday, March 28, 2013 12:34 PM SAFETY INSTRUCTIONS FOR MOBILE BASES 1. Place the mobile base on a level surface and adjust the feet before placing the machine in position. This should stop the machine rocking, while testing it for stability.
- Page 4 CUMB1 - Universal Mobile Base.fm Page 4 Thursday, March 28, 2013 12:34 PM ASSEMBLY INSTRUCTIONS ASSEMBLE THE CASTOR BRACKETS 1. Attach castor plate to the castor bracket using a pivot rod bolt and self locking nut . 2. Screw the adjustable foot into the threaded hole in the foot bracket.
- Page 5 CUMB1 - Universal Mobile Base.fm Page 5 Thursday, March 28, 2013 12:34 PM FITTING THE FIXED WHEELS 1. Position the wheel as shown. 2. Insert the 1¾” Wheel Axle Bolt through hole in the outer edge of the wheel housing, wheel, and secure to corner using a self locking nut.
- Page 6 CUMB1 - Universal Mobile Base.fm Page 6 Thursday, March 28, 2013 12:34 PM CONNECTING THE FOUR CORNERS TOGETHER 1. Select and arrange the corners and side rails necessary to assemble the base to suit your machine’s footprint. 2. Bolt the side rails to the corners...
- Page 7 CUMB1 - Universal Mobile Base.fm Page 7 Thursday, March 28, 2013 12:34 PM PLACING YOUR MACHINE ON THE BASE 1. With assistance, lift your machine or item to be mobilized into place. ORIENTATION The feed direction must be at right angle to the orientation of the fixed wheels to prevent the base from moving during machine operation.
- Page 8 CUMB1 - Universal Mobile Base.fm Page 8 Thursday, March 28, 2013 12:34 PM...
