Summary of Contents for Clarke CSA10EP
- Page 1 WARNING: Read these instructions before using the press 10 TONNE HYDRAULIC PRESS MODEL NO: CSA10EP PART NO: 7614025 OPERATION & MAINTENANCE INSTRUCTIONS GC0316...
-
Page 2: Product Specifications
INTRODUCTION Thank you for purchasing this CLARKE 10 Tonne Hydraulic Press. Before attempting to operate the machine, it is essential that you read this manual thoroughly and carefully follow all instructions given. In doing so you will ensure the safety of yourself and that of others around you, and you can also look forward to the press giving you long and satisfactory service. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS • Always read the operating instructions thoroughly before using this press. • The components of this press are specially designed to withstand the rated capacity. Do not substitute bolts, pins, or any other components. Do not exceed the rated capacity of the press. •... - Page 4 Ensure the press components suffered no damage during transit and that all components are present. Should any loss or damage become apparent, please contact your CLARKE dealer immediately. Due to the weight of the components, we recommend that the press is assembled by two people.
- Page 5 The press must be firmly secured to a firm and level floor using expansion bolts (not supplied). Holes are provided in the foot sections for this purpose. Do not locate your press where it will be open to the elements, as harsh weather conditions will damage the hydraulic parts.
- Page 6 7. Insert the bed support pins into the holes in the side support at a height of your choosing. Then lower the pressing bed onto the pins. 8. Use the retaining clips to stop the pins from passing through the side supports.
-
Page 7: Operation
OPERATION WARNING: FAILURE TO HEED THE WARNINGS ON PAGE 3 MAY RESULT IN DAMAGE TO THE EQUIPMENT OR COMPONENT FAILURE RESULTING IN PROPERTY DAMAGE, PERSONAL, OR EVEN FATAL INJURY. NEVER USE EXTENSIONS TO THE RAM PUMPING HANDLE 1. The press is now ready for use. Place the workpiece on the bed. It must be completely stable and supported by packing or shims where required. -
Page 8: Maintenance
Oil should be level with the bottom of the hole. If necessary top up with CLARKE hydraulic oil, Part No. 3050830. This task is carried out with the ram fully retracted. -
Page 9: Troubleshooting
TROUBLESHOOTING Problem Probable Cause Remedy Press will not work. Dirt on valve seat/warn Bleed jack unit or have unit seals within jack. overhauled with new seals. Jack will not produce Air-lock in jack. Open the release valve and pressure remove the oil filler plug. Jack feels hesitant Pump the handle a couple under load. - Page 10 FRAME PARTS DIAGRAM DESCRIPTION DESCRIPTION Cross Beam Bolt M8 x 20 Bolt M12 x 30 Washer 8 mm Washer 12 mm Nut M8 Nut M12 Bolt M8 x 25 Column Spring Foot Brace Bottle Jack Unit Bottom Fixing Plate Moving Beam Pressing Plate Pressing Bed Handle...
- Page 11 PUMP (JACK) PARTS DIAGRAM DESCRIPTION DESCRIPTION DESCRIPTION Adjustable Saddle Reservoir Seal Pump Saddle Socket Base Plate Washer O-ring Piston Rod Filter Screen Back Ring Oil Filler Plug Plunger O-ring Release Valve R-Clip Seal Release Valve Seal Piston Ball 6mm Short Pin Bowl Washer Ball Stopper Link Plate...
