DP Megacontrol Series Installation And Operating Instructions Manual page 43

3-4-3-5-4 No flow max. power
3-4-3-9 VFD Ramp-Up
3-4-3-10 VFD Ramp-Down
3-4-3-11 VFD min. frequency
3-4-3-12 VFD max. frequency
3-4-3-13 P nominal of VFD
3-4-3-14 U nominal of VFD
3-4-3-15 F nominal of VFD
3-4-3-16 I nominal of VFD
3-4-3-17 RPM nominal of VFD
3-4-3-18 BCC Failure DelayCnt
3-4-3-19 ARW delay factor
3-4-3-20 Motor Speed Unit
3-4-3-21 Digital I/P 33 func.
3-4-3-22 Digital I/P 29 func.
3-4-3-23 Jog frequency
3-4-3-24 Jog ramp time
3-4-3-25 Costing select
3-4-3-26 Start select
0 s s No flow detection is active below this Pump load in
100 %
0.1 e s Setting of the ramp-up of the VFD
3
999
0.1 e s Setting of the ramp-down of the VFD
3
999
0 e s Minimum frequency of the VFD
30
140
30 e s Maximum frequency of the VFD
50
140
0 e s nominal power of the VFD
1500
100000
0 e s nominal voltage of the VFD
400
500
50 e s nominal frequency of the VFD
140
0 e s nominal current of the VFD
4
450
0 e s nominal speed of the VFD
2880
10000
0 d d BCC Failure Delay Count
1
200
5 d d Setting for ARW control, sampletime factor tarw
50 >= 5 * ts
200
RPM e s Unit of motor speed
Hz
No Function e s Selection of digital input
Coasting stop inv.
No Function e s Selection of digital input
Jog Function
Jog Function
30 e s Motor speed manual mode
50
0.04 e s Ramp time
5
3600
Digital Input e s Selection manual mode
Bus
Digital And Bus
Digital Or Bus
Digital Input e s Selection start signal
Bus
Digital And Bus
Digital Or Bus
43
