30" x 18" U - Shaped Undersink Drawer
1
Parts
Drawer
2
Aligning Glide Frame
Align glide frame in cabinet using
alignment guide and measurements
shown below.
Make sure arrows are
pointing to the front of
the cabinet.
3
Checking Cabinet Clearance
Set drawer onto glide frame with
mounting holes on drawer and
glide frame aligned.
Check for adequate cabinet, door,
hinge, and plumbing clearance.
Adjust glide frame position
if needed.
Cabinet, door and
hinge clearance
30" x 18" U - Shaped Undersink Drawer
#453018
4"
min.
101.6mm
Alignment
Guide
Plumbing
clearance
R7-2
Discard (4x)
Glide
Frame
2"
min.
50.8mm
4"
min.
101.6mm
1
© 2017 Lynk, Inc. 8241 Melrose Dr. Lenexa, KS 66214
#453018
Parts Bag Includes
Mounting
Screw (4)
Wood
Screw (4)
Instructions
Alignment Guide
