Roll Out Bin Holder
1
Unpack
Glide
Frame
2
Attach Front Support
Attach front support onto base
using hex nuts found in parts bag.
Tighten hex nuts using wrench
found in parts bag.
3
Attach Rear Support
Place bin at the front of base to identify
rear holes that match bin size.
Attach rear support into holes that match
bin size using hex nuts.
Tighten hex nuts using wrench.
Wrench
430121 Roll Out Bin Holder
Base
Support
with handle
Hex Nut
Wrench
Hex Nut
R1
Rear
Support
Parts
Front
Support
with handle
Front
1
Parts Bag Includes:
Hex Nut (4x)
Mounting Screw
Wood Screw (4x)
Bag
Wrench
•
Instructions
•
Alignment Guide
Rear
Support
© 2016 Lynk, Inc. 8241 Melrose Dr. Lenexa, KS 66214
#430121
(4x)
Additional
holes for
larger bins
