BOOKLETMAKER FOLDNAK M2
Machine does not staple although the staple magazine is filled
Driver blade (16) is not hinged onto pin
(17):
Driver blade (16) is missing:
Staple jam inside staple magazine:
Staple pusher (12) does not push staples: Push staple pusher gently down to unlock
Staple jam inside staple channel:
Frequent misstapling or two staples in one position
Insufficient staple quality:
Incorrect staple type:
Driver blade (16) has been put in the
wrong way round:
Residues inside staple channel:
Driver blade (16) is scratched or bent:
Button „START" (6) is being pushed
without paper inside the machine:
7
Hinge hole of the driver blade (16) onto
pin (17).
Put in a driver blade. The mark "26" must
show towards the rear side of the ma-
chine.
Use original NAGEL-Staples and make
sure to only use types 26/6 or Ri 26/6.
and guide it towards the staples.
Take off stapling head, remove both
screws of front plate (18), take off front
plate. Remove jammed staple, clean staple
channel and reassemble. Use only original
NAGEL-Staples and make sure to only
use types 26/6 or Ri 26/6.
Use original NAGEL-Staples.
Use original NAGEL-Staples, types 26/6
or Ri 26/6 only. See chapter 2.
Put in the driver blade with the mark "26"
showing towards the rear side of the ma-
chine.
Take off stapling head, remove both
screws of front plate (18), take off front
plate. Clean staple channel and reassemble
the stapling head.
Put in a new driver blade.
Remove jammed staples from the anvils
and fire only with paper being inserted.
