BOOKLETMAKER FOLDNAK M2

3. ADJUSTMENTS

3.1 PAPER WIDTH

• Position the left side guide (10) according to the paper format required using the
scale (2) and fix it with the knurled screw (1)
• Insert paper squaring it up parallel to the left guide (10)
• Shift the right side guide (11) closely to the inserted paper and fix it, leaving 1mm of
air. Important: The side guides (10, 11) must not catch on the movement of the
sheets.

3.2 PAPER LENGTH

• Open cover (5)
• Adjust and fix the back stop (14) according to your paper format using the scale
• Close cover (5)
Check the adjustments 3.1 and 3.2 with a test run and readjust if necessary.

3.3 POSITION OF STAPLING HEADS

The BOOKLETMAKER FOLDNAK M2 is able to use four stapling positions with up
to four stapling heads (USA: 5 stapling positions with up to three stapling heads).
DIN-distances between the stapling heads are 50x80x50mm (USA: 2 1/8" on center).
• Unlock the latch (15)
• Take out stapling head, put it into a new position and lock the latch (15). The driver
blade's (16) hole needs to be hinged onto the pin (17), and the mark "26" on the
driver blade must show towards the rear side of the machine.
