Nibe F1126 Installation Manual

Ground source heat pump
Hide thumbs Also See for F1126:
Table of Contents

Advertisement

Quick Links

Download this manual
IHB EN 2008-1
531657
Ground source heat pump
NIBE F1126
INSTALLATION MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Nibe F1126

Summary of Contents for Nibe F1126

  • Page 1 IHB EN 2008-1 INSTALLATION MANUAL 531657 Ground source heat pump NIBE F1126...
  • Page 2 HEAT PUMP 12 hrs To temporarily increase the amount of hot water (if a hot water heater is installed to your F1126), first turn the control knob to mark menu 2 (water droplet) and then press the OK button twice.

  • Page 3: Table Of Contents

    Cold and hot water Energy labelling Docking alternatives Electrical circuit diagram 5 Electrical connections Item register General Connections Contact information Settings Optional connections Connecting accessories 6 Commissioning and adjusting Preparations Filling and venting Start-up and inspection NIBE F1126 Table of Contents...

  • Page 4: Important Information

    The overflow pipe must be visible and its mouth must be open and not located close to electrical components. F1126 must be installed via an isolator switch. The cable area has to be dimensioned based on the fuse rating used.

  • Page 5: Serial Number

    This unit contains a fluorinated greenhouse gas that is covered by the Kyoto agreement. The equipment contains R407C, a fluorinated green- house gas with a GWP value (Global Warming Potential) of 1,774. Do not release R407C into the atmosphere. NIBE F1126 Chapter 1 | Important information...

  • Page 6: Inspection Of The Installation

    Particle filter Safety valve Shut off valves Circulation pump setting Electricity (page Connections Main voltage Phase voltage Fuses heat pump Fuses property Outside sensor Safety breaker Earth circuit-breaker Setting of emergency mode thermostat Chapter 1 | Important information NIBE F1126...

  • Page 7: Delivery And Handling

    Approx. 50 mm free space is required on each side, to remove the side panels (see image). The panels do not need to be removed during service. All service on F1126 can be carried out from the front. Leave space between...

  • Page 8: Supplied Components

    Remove the screws from the upper and lower edges. Twist the cover slightly outward. Move the hatch outwards and backwards. Assembly takes place in the reverse order. Chapter 2 | Delivery and handling NIBE F1126...

  • Page 9: The Heat Pump Design

    Motor module Immersion heater Switch MISCELLANEOUS EP14 Cooling section Rating plate Type plate, cooling section Cable gland, incoming electricity Cable gland Cable gland, rear side, sensor Designations according to standard EN 81346-2. NIBE F1126 Chapter 3 | The heat pump design...

  • Page 10: Distribution Boxes

    * 5 kW has auxiliary switch for motor protection breaker. Base card Miniature circuit-breaker FQ10 Temperature limiter/Emergency mode thermostat Terminal block MOTOR MODULE (AA11) 3x400 V 6-8 kW AA10 3x400V 12 kW FC10 AA10 ELECTRICAL COMPONENTS AA10 Soft-start card Chapter 3 | The heat pump design NIBE F1126...

  • Page 11: Cooling Section (Ep14)

    6 & 8 kW BT17 Temperature sensor, suction gas ELECTRICAL COMPONENTS AA100 Joint card GQ10 BT14 EB10 Compressor heater COOLING COMPONENTS BT17 BT15 Evaporator XL21 Condenser GQ10 Compressor Drying filter EB10 XL20 Expansion valve NIBE F1126 Chapter 3 | The heat pump design...

  • Page 12: Pipe Connections General

    70 (63 °C with only Non-return valve the compressor). Circulation pump F1126 is not equipped with external shut off valves; Expansion vessel these must be installed to facilitate any future servicing. Auxiliary relay Caution Compressor Ensure that incoming water is clean.

  • Page 13: Dimensions And Pipe Connections

    SYSTEM DIAGRAM Dimensions and pipe F1126 consists of heat pump, immersion heater, circu- lation pumps and control system. F1126 is connected connections to the brine and heating medium circuits. In the heat pump evaporator, the brine (water mixed with anti-freeze, glycol or ethanol) releases its energy to the refrigerant, which is vaporised in order to be compressed in the compressor.

  • Page 14: Brine Side

    Heating medium side CONNECTING THE CLIMATE SYSTEM A climate system is a system that regulates indoor comfort with the help of the control system in F1126 and for example radiators, underfloor heating/cooling, fan convectors etc. • Install all required safety devices, shut-off valves (as close to the heat pump as possible), and supplied particle filter.

  • Page 15: Cold And Hot Water

    • Fit safety valve on heating medium return as illus- FIXED CONDENSING trated. Recommended opening pressure is 0.25 MPa If F1126 is to work towards a water heater with fixed (2.5 bar). For information about max opening pressure, condensing, you must connect external supply temper- see technical specifications.
  • Page 16 UNDERFLOOR HEATING SYSTEM The installation can be supplemented with the exhaust The external circulation pump is dimensioned for the air module NIBE FLM to provide ventilation recovery. under floor heating system’s demand. • Pipes and other cold surfaces must be insulated with If the climate system volume is too small for the heat diffusion-proof material to prevent condensation.

  • Page 17: Electrical Connections

    AA11-FC10/FC1 cables to external connections must be 0.5 mm² up to 50 m, for example EKKX or LiYY or equivalent. • When cable routing in F1126, cable grommets (e.g. UB1-UB3, marked in image) must be used. In MINIATURE CIRCUIT-BREAKER UB1-UB3 the cables are inserted through the heat The heat pump operating circuit and some of its internal pump from the back to the front.
  • Page 18 Removing the cover, terminal block Check the miniature circuit-breaker, temperat- ure limiter and motor protection breaker. They Unscrew the screws and angle out the cover. may have tripped during transportation. Pull off the cover. Chapter 5 | Electrical connections NIBE F1126...

  • Page 19: Connections

    20 cm to high voltage cable when cable routing. POWER CONNECTION F1126 must be installed with a disconnection option on the supply cable. Minimum cable area must be sized according to the fuse rating used. Enclosed cable for incoming supply electricity is connected to terminal block X1 on the immersion heater board (AA1).
  • Page 20 If you wish to connect external operating voltage for the placed in the submerged tube on the water heater. control system to F1126 on the immersion heater circuit Connect the sensor to terminal block X1:9 and X1:10. board (AA1) the edge connector at AA1:X2 must be Use a 2 core cable of at least 0.5 mm²...

  • Page 21: Settings

    The switch (SF1) must not be moved to "" or is done in menu 5.1.12. " " until F1126 has been filled with water. The table displays the total phase current for the immer- Components in the product can be damaged.

  • Page 22: Optional Connections

    Optional connections 9 kW) EXTERNAL CONNECTION OPTIONS On the terminal block (X1), F1126 has software-con- trolled AUX inputs for connecting external switch func- tion or sensor. This means that when an external switch function (the switch must be potential-free) or sensor...
  • Page 23 NIBE ECS 40/41 should be used for optimum operation. External activation of functions An external switch function can be connected to F1126 • SG ready to activate various functions. The function is activated during the time the switch is closed.

  • Page 24: Connecting Accessories

    External blocking of functions An external switch function can be connected to F1126 for blocking various functions. The switch must be po- tential-free and a closed switch results in blocking. NOTE Blocking entails a risk of freezing. Functions that can be blocked: •...

  • Page 25: Commissioning And Adjusting Preparations

    Open the valves on the filler connector. NOTE Start the filling pump. Do not start F1126 if there is a risk that the Fill until liquid enters the return pipe. water in the system has frozen. Close the valves on the filler connector.
  • Page 26 Set switch (SF1) on F1126 to position "". Name and menu number Follow the instructions in the display’s start guide. Here, you can see which menu in the control system If the start guide does not start when you start the this page of the start guide is based on.
  • Page 27 POST ADJUSTMENT AND VENTING F1126 12 kW Pump adjustment Available pressure, kPa Tillgängligt tryck, kPa Eleffekt, W Electrical output, W Brine side, manual operation Tillgängligt tryck, kPa P100% To set the correct flow in the brine system the correct Eleffekt, W speed must be set for the brine pump.

  • Page 28: Setting The Heating Curve

    P80% indoor temperature, regardless of the outdoor temper- ature, and thereby energy-efficient operation. Based on P60% this curve, the F1126 determines the temperature of P40% the water to the climate system (the supply temperat- ure) and thus the indoor temperature.
  • Page 29 You can now select to take read outs for different outdoor temperatures by turning the control knob to the right or left and read off the corresponding flow temperature. Press the OK or Back button to exit read off mode. NIBE F1126 Chapter 6 | Commissioning and adjusting...

  • Page 30: Control - Introduction

    • confirm selections of sub menus/options/set values/page in the start guide. BACK BUTTON The back button is used to: • go back to the previous menu. • change a setting that has not been confirmed. Chapter 7 | Control - Introduction NIBE F1126...

  • Page 31: Menu System

    Advanced settings. These settings are only intended for installers or service engineers. The menu is visible when the Back button is pressed for 7 seconds, when you are in the start menu. See page NIBE F1126 Chapter 7 | Control - Introduction...
  • Page 32 To select another option: Mark the applicable option. One of the options is pre-selected (white). Press the OK button to confirm the selected option. The selected option has a green tick. Chapter 7 | Control - Introduction NIBE F1126...
  • Page 33 Scroll through the windows in the start guide language 4.6 start guide NIBE F1126 Arrows to scroll through window in start guide Turn the control knob until one of the arrows in the top left corner (at the page number) has been marked.

  • Page 34: Control - Menus

    Menu 3 - INFO 3 - INFO 3.1 - service info 3.2 - compressor info 3.3 - add. heat info 3.4 - alarm log 3.5 - indoor temp. log * Accessories are needed. Chapter 8 | Control - Menus NIBE F1126...

  • Page 35: Menu 4 - Heat Pump

    4.4 - time & date 4.6 - language 4.9 - advanced 4.9.1 - op. prioritisation 4.9.2 - auto mode setting 4.9.3 - degree minute set- ting 4.9.4 - factory setting user * Accessory needed. NIBE F1126 Chapter 8 | Control - Menus...

  • Page 36: Menu 5 - Service

    Factory setting stop temp. lux: 53 °C NOTE stop temp. per. increase Incorrect settings in the service menus can damage the heat pump. Setting range: 55 – 70 °C Factory setting: 55 °C Chapter 8 | Control - Menus NIBE F1126...
  • Page 37 Setting range: 0 - 100 % The different alternatives are that the heat pump stops Default values: 50 % producing hot water (default setting) and/or reduces the room temperature. NIBE F1126 Chapter 8 | Control - Menus...
  • Page 38 Caution Here you set the max. electrical output of the internal The change log is saved at restart and remains electrical addition in F1126 and the fuse size for the in- unchanged after factory setting. stallation. Chapter 8 | Control - Menus...
  • Page 39 This allows access to country-specific settings in your product. Language settings can be made regardless of this selec- tion. Caution This option locks after 24 hours, after restarting the display or program updating. NIBE F1126 Chapter 8 | Control - Menus...

  • Page 40: Service

    EMERGENCY MODE NOTE The switch (SF1) must not be moved to "" or " " until F1126 has been filled with water. Component parts in the product can be dam- The image shows an example of what a cooling section aged.
  • Page 41 It is usually easier to start the circulation pump with drain the system first. This can be done in different ways F1126 running, and with the switch (SF1) set to "". If the depending on what needs doing: circulation pump is helped to start while F1126 is run-...
  • Page 42 Close the shut-off valves (QM31), (QM32), (QM33) and (QM34). Drain the compressor module according to the in- structions on page 40 QM31 QM33 F1145 QM34 QM32 Pull off the lock catches. Disconnect the pipe connection under the shut-off valve (QM31). Chapter 9 | Service NIBE F1126...
  • Page 43 Disconnect the switch (D) from the joint board (AA100). Carefully pull out the cooling module. The display unit is equipped with a USB socket that can be used to update the software and save logged inform- ation in F1126. NIBE F1126 Chapter 9 | Service...
  • Page 44 When you have selected a This allows you to update the software in F1126. file with the OK button you will return to the previous page (menu 7.1) where you can choose to start the up-...
  • Page 45 Here you can choose how current measurement values from F1126 should be saved onto a log file on the USB memory. Set the desired interval between loggings. Tick “activated". The present values from F1126 are saved in a file in the USB memory at the set interval until “activ- ated"...

  • Page 46: Disturbances In Comfort

    10 Disturbances in comfort In most cases, F1126 notes a malfunction (a malfunction aid mode “aid mode” is a type of emergency mode. can lead to disruption in comfort) and indicates this with This means that the heat pump produces heat and/or alarms, and instructions for action, in the display.
  • Page 47 • There is no heating requirement. • F1126 in incorrect operating mode. – F1126 does not call on heating or hot water. – Enter menu 4.2. If mode "auto" is selected, select a • Compressor blocked due to the temperature condi- higher value on "stop heating"...
  • Page 48 – Adjust the flow distribution between the radiators. GURGLING SOUND This part of the troubleshooting chapter only applies if the NIBE FLM accessory is installed. • Not enough water in the water seal. – Refill the water seal with water.

  • Page 49: Accessories

    Part no. 067 666 EXTRA RELAY CARD EXC 40 Extra relay board required if ground water pump and/or hot water circulation pump is to be connected to F1126. The extra relay card is installed inside the heat pump. Part no. 067 072 FILLING VALVE KIT KB 25 Valve kit for filling brine in the collector hose.

  • Page 50: Technical Data

    Dimensions and setting-out coordinates * This dimension applies at 90° angle on the brine pipes (side connection). The dimension can vary approx. ±100 mm vertically as the brine pipes consist in part of flexible pipes. Chapter 12 | Technical data NIBE F1126...

  • Page 51: Electrical Data

    1/2/3/4/5/6/7 (switchable to 2/4/6/9) Output, Brine pump 3 – 180 Output, Heating medium pump 4 – 70 Enclosure class IPX1B Equipment Compliant with IEC 61000-3-12 For Connection Design Purposes, Compliant with IEC 61000-3-3 technical requirements NIBE F1126 Chapter 12 | Technical data...

  • Page 52: Technical Specifications

    Scale for the system’s efficiency class room heating: A+++ to G. Reported efficiency for the system takes the product’s temperature regulator into account. Scale for efficiency class hot water: A+ to F. With feet removed, the height is approx. 1,650 mm. Chapter 12 | Technical data NIBE F1126...
  • Page 53 Incoming brine temp, °C Köldbärare in Framledning Flow pipe (°C) Returledning Return pipe 6 - 8 kW 3x400V Text text bla bla Temperature, °C (enhet) Incoming brine temp, °C Flow pipe Return pipe NIBE F1126 Chapter 12 | Technical data...

  • Page 54: Energy Labelling

    Energy labelling INFORMATION SHEET Supplier NIBE AB Model F1126-6 3X400V F1126-8 3X400V F1126-12 3X400V Model hot water heater VPB300 VPB300 VPB300 Temperature application °C 35 / 55 35 / 55 35 / 55 Declared load profile for water heating Seasonal space heating energy efficiency class, aver-...
  • Page 55 Daily energy consumption 9.92 Daily fuel consumption elec fuel Annual energy consumption 2,178 Annual fuel consumption Contact information NIBE Energy Systems – Box 14 – Hannabadsvägen 5 – 285 21 Markaryd – Sweden NIBE F1126 Chapter 12 | Technical data...
  • Page 56 Daily energy consumption 9.77 Daily fuel consumption elec fuel Annual energy consumption 2,145 Annual fuel consumption Contact information NIBE Energy Systems – Box 14 – Hannabadsvägen 5 – 285 21 Markaryd – Sweden Chapter 12 | Technical data NIBE F1126...
  • Page 57 Daily energy consumption 10.38 Daily fuel consumption elec fuel Annual energy consumption 2,280 Annual fuel consumption Contact information NIBE Energy Systems – Box 14 – Hannabadsvägen 5 – 285 21 Markaryd – Sweden NIBE F1126 Chapter 12 | Technical data...

  • Page 58: Electrical Circuit Diagram

    Electrical circuit diagram 3X400 V 6-12 KW Chapter 12 | Technical data NIBE F1126...
  • Page 59 NIBE F1126 Chapter 12 | Technical data...
  • Page 60 Chapter 12 | Technical data NIBE F1126...
  • Page 61 NIBE F1126 Chapter 12 | Technical data...
  • Page 62 Chapter 12 | Technical data NIBE F1126...

  • Page 63: Item Register

    Supplied components, 8 Removing the hatch, input circuit board, 18 Transport, 7 Settings, 21 Dimensions and pipe connections, 13 Standby mode, 21 Dimensions and setting-out coordinates, 50 Temperature limiter, 17 Display, 30 Temperature sensor, hot water charging, 20 NIBE F1126 Item register...
  • Page 64 Electrical circuit diagram, 58 General, 12 Energy labelling, 54 Heating medium side, 14 Data for energy efficiency of the system, 54 Pipe dimensions, 13 Information sheet, 54 Symbol key, 12 Technical documentation, 55 System diagram, 13 Technical Data, 52 Item register NIBE F1126...
  • Page 65 Component location cooling section, 11 Component location electrical cabinets, 10 Component locations, 9 List of components, 9 Transport, 7 Troubleshooting, 46 USB service outlet, 43 Wiring diagram 3x400V 6-12 kW, 58 Working range heat pump, 53 NIBE F1126 Item register...

  • Page 67: Contact Information

    Tel: +46 (0)433-27 3000 kuzmin@evan.ru info@nibe.se nibe-evan.ru nibe.se SWITZERLAND NIBE Wärmetechnik c/o ait Schweiz Industriepark, CH-6246 Altishofen Tel. +41 (0)58 252 21 00 info@nibe.ch nibe.ch For countries not mentioned in this list, contact NIBE Sweden or check nibe.eu for more information.
  • Page 68 WS release date: 2020-02-21 13:45 Publish date: 2020-03-24 12:28 This manual is a publication from NIBE Energy Systems. All product illustrations, facts and data are based on the available information at the time of the publication’s approval. NIBE Energy Systems makes reservations for any factual or printing errors in this manual.
