Non-applicable Existing System

The following equipment can not be upgraded. Their recommended substitute products are
shown in the table.
Component
Table Recommended Substitute Products
Equipment out of
scope of upgrade
CFGW, EFGW (*1)
CGWU, ECGWZ,
ECGW2, ECGW3
EFUS, EFUD
CFBS2
EMCS, EMCD
CCMS, ECMP
XLAIS
YEWLINK
*1: If CFGW or EFGW is used in the existing system, FIO's communication modules (ALR111/ALR121 and ALE111 cards) should be
added to the field control station (FCS). Application software should also be regenerated.
I/O Card
Table Recommended substitute device
Equipment of scope of upgrade
RS4
*1: If the CFGW and EFGW are already incorporated in the existing system, FIO's communication modules (ALR111/ALR121 and
ALE111 cards) should be included in the field control station (FCS). Application software should also be regenerated.
*2: For details, see GS 33M50J10-40E for Cables.
Recommended substitute
FFCS-V + ALR111/121
communication module
FFCS-V + ALE111
communication module
ACG, general purpose PC
FFCS, FFCD
FFCS, FFCD
FFCS, FFCD, APCS
General-purpose PC
General-purpose PC
Optical repeater
Recommended substitute device
ALR111
3. Scope of Upgrade
Remarks
Subsystem communication package
(for serial communication, e.g., RS-232C, RS-485)
Subsystem communication package (for Ethernet)
Communications software should be restructured
with Exaopc.
Application software should be restructured with
Exaquantum, Exaopc packages, etc.
Exapilot package
Use new cables that support
different shape connectors. (*2)
3-3
Remarks
