Quick Installation Guide
APC Assembling and Mounting
The APC Propeller 2 and APC Propeller 5 units are supplied with mounting hardware
for pole or wall installations. Follow the steps for APC Propeller 2 or APC Propeller 5
assembling and mounting on a preferable surface.
Step 1.
Make sure that the APC unit is powered-off.
Insert the UTP cable into the APC unit's ETH port through the insert
Step 2.
bracket (tem 2 in the Figure 1 – Package Contents) and as displayed in
the picture below:
It is recommended to use shielded STP Ethernet cable to reduce
exposure of the electromagnetic noise.
Connect unit with the insert bracket (item 2 in the Figure 1 – Package
Step 3.
Contents):
deliberant
Installation
Page 10
