SAJ R5-3K-T2 User Manual page 18

Grid Monitoring
AC Short Circuit Current Protection
AC Grounding Detection
DC Surge Protection
AC Surge Protection
Thermal Protection
String Current Detection
Anti-island Protection Monitoring
Interface
AC Connection
DC Connection
Human Machine Interface
Communication Port
Communication Mode
General Data
Topology
Consumption at Night [W]
Consumption at Standby [W]
Operating Temperature Range
Cooling Method
Ambient Humidity
Altitude
Noise [dBA]
Ingress Protection
Mounting
Dimensions [H*W*D][mm]
Weight [kg]
Standard Warranty [Year]
Applicable Standard
Manufacturing country
*
Notes: 1. The maximum AC output power of Belgium is rated AC output power.
2. The above parameters might be slightly modified according to different grid codes.
3. If you need more information about our product certifications, please contact our sales.
LED+(Bluetooth/Wi-Fi+APP)
RS232(USB)+RS485(RJ45)
Wi-Fi/GPRS/4G(Optional)
-40℃～+60℃[45°C to 60°C with derating]
Natural Convection
0%～100% Non-condensing
4000m(>3000m power derating)
480*440*200
26
5 (standard)/10/15/20/25 (Optional)
CQC NB/T 32004,EN 62109-1/2,EN 61000-6-1/2/3/4
EN50438,EN50549,C10/C11,IEC 62116,IEC 61727,RD
1699,UNE 206006,UNE 206007-1,CEI0-16,G99
- 17 -
Integrated
Integrated
Integrated
Integrated
Integrated
Integrated
Integrated
AFD
Terminal Block
MC4
Transformerless
<0.6
<10
<29
IP65
Rear Panel
530*490*210
China
R5
Series
29
