Sol-Ark-12K-P Specifications
Solar
Output Power 12000W
Max allowed PV DC Capacity
Max PV power delivered to Battery & AC outputs
Max DC voltage
MPPT voltage range
MPPT Starting voltage
Number of MPPT
Solar Strings per MPPT
Max DC current per MPPT (self limiting)
Max AC Coupling (Gen Breaker / Load Breaker)
AC
Output Power 9600W On Grid & 8000W Off Grid
Connecti ons
Continuous AC power to Grid (On Grid)
Continuous AC power to Loads (Off Grid)
Surge AC power 10sec
Surge AC power 16ms
Parallel Stacking
Frequency
Continuous AC power with Grid or Ge nerator
CEC Efficiency
Idle Consumption typical – no load
Sell back power modes
Design (DC to AC)
Response Time (Grid-Tied to Off-Grid)
Power Factor
Battery
(optional) Output Power 8000W
Type
Nominal DC Input
Capacity
Voltage Range
Continuous Battery charging output
Charging curve
Grid to Battery Charging Efficiency
External temperature sensor
Current shunt for accurate % SOC
External Generator Start based on voltage or % SOC
Communication to L ithium battery
General
Dimensions (H x W x D)
Weight
Enclosure
Ambient Temperature (3 variable speed fans)
Display
Wi-Fi Communication (monitoring or SW updates)
Snap on sensors for limited selling to Ho usehold
Standard Warranty (verified by HALT testing)
8,250W+8,250W = 16,500W
12000W
500V@18A, 450V@20A
150-425V
175V
2
2 w/o fuses, 3 w/ fuses
20A@300V, 18A@400V
7,600W / 9,600W
120/240/208V split phase
9600W 37.5A L - L (255V)
4800W 40A L-N (120V)
8000W 33A L-L (240V)
4800W 40A L-N (120V)
16,000VA L-L (240V)
25,000VA L-L (240V)
2-8 (240V), 3-9 (208V)
60/50Hz
12000W 50A L-L (240V)
6000W 50A L-N (120V)
96.5% (Peak 97.5%)
60W
Limited to Household or
Full Grid-Tied
Transformerless DC
4ms
+-0.9 - 1.0
Lead-Acid or Li-Ion
48V
50 – 9900Ah
43.0 – 63.0V
185A
3-stage w/ equalizati on
96.0%
included
integrated
integrated
CanBus & RS485
30.0" x 16.75" x 9.37"
74 lbs
NEMA type 1 (Indoor Use)
-25 to 55C, >45C derating
Color touch screen
included
included
10 years
February 3, 2020
Protection & Certifications
Electronics certified safety by SGS labs to NEC
& UL specs – NEC 690.4B & NEC 705.4/6
Grid Sell Back – UL1741-2010/2018,
IEEE1547a-2003/2014, FCC 15 class B,
UL1741SA, CA Rule 21, HECO Rule 14H
PV DC disconnect switch – NEC 240.15
Ground Fault Detection – NEC 690.5
PV rapid shutdown control – NEC 690.12
PV Arc Fault detection – NEC 690.11/
UL1699B
PV input lightning protection
AC input/output 50A breakers
250A Battery breaker / disconnect
User wiring enclosure w/ ¾" & 1" knock-outs
Solar Flare/EMP Hardened to 2015 MIL -STD-
461G (Independently tested June 2018)
Yes
Yes
integrated
integrated
integrated
integrated
integrated
integrated
integrated
integrated
optional
27
