Universal Tool UT5762 Operator Instructions

Operator Instructions
Includes - Foreseen Use, Work Stations, Putting Into Service, Operating,
Dismantling, Assembly and Safety Rules
Manufacturer/Supplier
Universal Air Tool Company Limited
Unit 8
Lane End Industrial Park
High Wycombe
Bucks
HP14 3BY
Tel No (01494) 883300
Product Nett Weight
lbs
1.7
Kg
0.8
Air Pressure
Recommended Working
Recommended Minimum
Maximum
Personal Safety Equipment
Use - Safety Glasses
Use - Safety Gloves
Use - Safety Boots
Use - Breathing Masks
Use - Ear Protectors
Foreseen Use of the Tool
This tool is designed to be used with appropriate cutting discs only..
The tool should not be used with any other type of abrasive disc or
wheel. It must never be used with saw blades or other cutting devices.
Do not use the tool outside the design intent. Never modify the tool for
any other purpose, or for its use as a disc cutter without first seeking
advice from the manufacturer or an authorised representative.
Work Stations
The tool should only be used as a hand held hand operated tool. It is
always recommended that the tool is used when standing on a solid
floor. It can be used in other positions but before any such use the
operator must be in a secure position having a firm grip and footing and
be aware of the safety rules to be obeyed when using the grinder.
Putting Into Service
Air Supply
Use a clean lubricated air supply that will give a
measured air pressure at the tool of 90
p.s.i./6.3 bar when the tool is running with the
trigger/lever fully depressed.
recommended hose size and length. It is
recommended that the tool is connected to
the air supply as shown in figure 1. Do not
connect the tool to the air line system without
incorporating an easy to reach and operate air
shut off valve. The air supply should be
lubricated. It is strongly recommended that an
Fax No (01494) 883237
Recommended Use Of
Balancer Or Support
No
6.3 bar 90 PSI
n/a bar n/a PSI
7.0 bar 100 PSI
Yes
Yes
Yes
Yes
Use
Page No 1
Important
Read these instructions carefully before installing, operating,
servicing or repairing this tool. Keep these instructions in a safe
accessible place.
Product Type
Cut Off Tool
Model No/Nos
UT5762
Recommended Hose Bore
Size - Minimum
3/8 Ins 10 M/M
Noise Level Sound Pressure Level 86.0 dB(A)
Test Method Tested in accordance with Pneurop
test code PN8NTC1
Vibration Level Less than 2.5 Metres / Sec²
Test Method Tested in accordance with ISO
standard 8662
air filter, regulator, lubricator (FRL) is used as shown in Figure 1 as this
will supply clean, lubricated air at the correct pressure to the tool.
Details of such equipment can be obtained from your supplier. If such
equipment is not used then the tool should be lubricated by shutting off
the air supply to the tool, depressurising the line by pressing the trigger
on the tool. Disconnect the air line and pour into the intake bushing a
teaspoonful (5ml) of a suitable pneumatic motor lubricating oil
preferably incorporating a rust inhibitor. Reconnect tool to air supply
and run tool slowly for a few seconds to allow air to circulate the oil. If
tool is used frequently lubricate on daily basis and if tool starts to slow or
lose power.
It is recommended that the air pressure at the tool whilst the tool is
running is 90 p.s.i./6.3 bar.
RPM
20,000
Cycles Per Min
Serial No
Recommended Max.
Hose Length
30 Ft 10 M
