Universal Tool UT9930 User Manual

Description

The Universal Tool model UT9930 Recoilless Air Saw features an advanced vibration-dampened mechanism which allows
reciprocating saw action without the traditional associated vibrations being transferred to the operator. This tool is designed to cut
a variety of materials including sheet metal, auto body panels, ductwork, aluminum, fiberglass, plastics and wood. This tool
features a heavy duty steel housing and guide, front exhaust, and a lock-off throttle. Throttle rotates 360° and locks into desired
position for operation.

Specifications

Blade size ................................................................. 3 - 4 "
Stroke length ........................................................... 5/16"
Speed ......................................................... 9,600 S.P.M.
Overall length ......................................................... 8 1/4"
Weight .............................................................. 2 1/4 lbs.
Air inlet ............................................................. 1/4" NPT
Minimum hose size ............................................. 1/4" I.D.
Average air consumption ....................................... 3 CFM
Maximum operating pressure ................................ 90 PSI
Vibration level .........................................................2m/s
PL-2086
2
Universal Tool
A Division of Florida Pneumatic Manufacturing Corporation
851 Jupiter Park Lane, Jupiter, Florida 33458
Toll Free 1-800-327-9403
PLEASE READ AND FOLLOW ALL WARNINGS
Read Operating Instructions
Always become familiar with all the instruc-
tions and warnings before operating any
power tool.
Always Wear Approved Eye Protection
Impact resistant eye protection should meet
or exceed the standards as set forth in the
United States ANSI Z87.1, Occupational and
Educational Eye and Face Protection. Look
for the marking Z87.1 on your eye protection
to insure that it is an approved style. For
further information, ANSI Z87.1, Occupa-
tional and Educational Eye and Face
Protection, is available from the American
National Standards Institute, Inc., 11 West
42nd Street, New York, NY 10036.
Hearing Protection is Recommended
Hearing protection should be used when the
noise level exposure equals or exceeds an 8
hour time-weighted average sound level of
85 dBA. Process noise, reflective surfaces,
other tools being operated nearby, all add to
the noise level present in your work area. If
you are unable to determine your noise level
exposure, we recommend the use of hearing
protection.
Avoid Prolonged Exposure
to Vibration
Tools can vibrate during use. Prolonged
exposure to vibration or very repetitive hand
and arm movements, can cause injury. Stop
using any tool if discomfort, tingling feeling
or pain occurs. You should consult your
physician before resuming use of the tool.
90 PSIG Maximum
This tool is designed to operate at an air
pressure of 90 pounds per square
gauge pressure (90 PSIG) maximum, at the
tool. Use of higher air pressure can, and may
cause injury. Also, the use of higher air
pressure places the internal components
under loads and stresses they were not
designed for, causing premature tool failure.
The air supply should be clean and dry,
preferably lubricated. For best results, drain
the moisture from your compressor daily.
UT9930
Recoilless Air Saw
