MODEL N° 1270
OWNER'S MANUAL
Keep this Product ID Number and use when contacting Customer Service:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1270 and is the answer not in the manual?

Questions and answers

Related Manuals for Lifetime 1270

Summary of Contents for Lifetime 1270

  • Page 1 MODEL N° 1270 OWNER’S MANUAL Keep this Product ID Number and use when contacting Customer Service:...
  • Page 2 Maintaining your privacy is our long-standing policy at Lifetime. And you can rest as- sured that Lifetime will not sell or provide your personal data to other third parties, or allow them to use your personal data for their own purposes.

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS To ensure safety, do not attempt to assemble this product without reading and following all instructions carefully. Check the entire box and inside all packing materials for parts and/or additional instruction material. Before beginning assembly, identify and inventory all parts and hardware using the parts and hardware lists and identifi...
  • Page 4 TOOLS AND PARTS REQUIRED FOR THIS ASSEMBLY Phillips Screwdriver Pliers Rubber Mallet Sand (2, included) (319 lb) *Two adults required to complete assembly*...
  • Page 5 ASSEMBLY GUIDES Refer to the following areas throughout the instructions to assist in the assembly process: This area is located at the top, TOOLS AND HARDWARE REQUIRED FOR THIS PAGE left-hand corner of the page and indicates which tools and hardware are needed to on a page.

  • Page 6: Parts List

    PARTS LIST Item Description Top Pole Middle Pole Bottom Pole Right Backboard Bracket Backboard Base Pole Brace Wheel 1/2” x 15 3/4” Axle 1/2” x 7” Axle 5/16” Hex Knob Domed Countersink Washer Rim Support Channel Base Plug Warning Sticker (Applied to Middle Pole) HARDWARE LIST Item Description Pole Assembly Hardware (1066286)

  • Page 7: Parts Identifier

    PARTS IDENTIFIER Parts shown at 10% of Actual Size ALH (x1) *Do not remove Top Pole from Middle Pole until instructed Top Pole (x1) Middle Pole ALE (x1) ALI (x2) Bottom Pole Pole Brace ALX (x1) (x1) (x1) Right Backboard Bracket 7”...
  • Page 8 PARTS IDENTIFIER Part shown at 25% of Actual Size AOX (x1) Rim Support Channel AYU (x1) 5/16” Hex Knob AMU (x2) Wheel Parts shown at Actual Size (x2) CIH (x1) Base Plug Domed Countersink Washer Parts shown at 5% of Actual Size (x1) (x1) Base...

  • Page 9: Hardware Identifier

    HARDWARE IDENTIFIER Hardware shown at Actual Size ABD (x1) AOL (x2) 5/16” Washer 5/16” x 3 1/4” Carriage Bolt AAN (x1) AYT (x1) ADS (x1) 5/16” Cap Nut 5/16” Hex Nut 1/4” x 3/4” Screw Hardware shown at Actual Size BTS (x1) CII (x1) 1/4”...
  • Page 10 HARDWARE IDENTIFIER Hardware shown at Actual Size ADQ (x2) APN (x2) 5/16” x 1” Screw APK (x1)

  • Page 11: Hardware Required

    POLE ASSEMBLY HARDWARE REQUIRED Hardware shown at Actual Size AYT (x1) 5/16” Hex Nut AOL (x2) 5/16” x 3 1/4” Carriage Bolt ADS (x1) AAN (x1) ABD (x1) 1/4” x 3/4” Screw 5/16” Cap Nut 5/16” Washer PARTS REQUIRED Parts shown at 10% of Actual Size ALH (x1) *Do not remove Top Pole from Middle Pole until instructed Top Pole...
  • Page 12 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE While the Top Pole (ALH) is still inside the , pull the plastic off the Top Pole. It may be necessary to loosen the Poles before pulling out the plastic. Sticker Note: Make sure the crimped side of the Top Pole is on the same side as the Warning Sticker (AMT) on the Middle Pole.
  • Page 13 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 1/2” AOL (x1) AAN (x1) ABD (x1) Slide the Top Pole (ALH) far enough out of the so that it does not obstruct the holes at the bottom of the Middle Pole. Then attach the hardware indicated in the location shown.
  • Page 14 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE AOL (x1) AYT (x1) Insert a 5/16” Hex Nut (AYT) into the 5/16” Hex Knob (AYU) as shown. It may be necessary to use the to place the Nut in the Knob. Then position the Top Pole (ALH) at its lowest height and attach the Knob to the Top Pole and with the hardware shown.
  • Page 15 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE ADS (x1) Align the hole in the with the slot in the Bottom Pole (ALE) and slide the Middle Pole over the Bottom Pole. Insert a through the and the small hole in the Middle Pole and into the slot in the Bottom Pole as shown.
  • Page 16 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE ATTENTION: THIS STEP CANNOT BE REVERSED! In order to seat the Poles, strike the end of the Bottom Pole (ALE) very hard fi ve to six times on a piece of scrap wood or cardboard. This must be done even if the covers the slot on the Bottom Pole before seating has occurred.
  • Page 17 POLE TO BASE ASSEMBLY HARDWARE REQUIRED Hardware shown at Actual Size AAE (x2) ABD (x4) BTS (x1) ABN (x2) 5/16” x 1” Hex Bolt 5/16” Washer 1/4” Barrel Nut 1/2” x 1/8” Spacer CII (x1) AAO (x2) 1/4” x 2 3/4” Shoulder Bolt 5/16”...
  • Page 18 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE AAE (x2) AAO (x2) ABD (x4) ABN (x2) Attach the fl attened end of the Pole Brace (ALI) to the with the hardware shown. Only fi nger tighten the hardware. Note: Repeat this step to install the other Pole Brace to the other side of the Base.
  • Page 19 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 1/2" (x2) CII (x1) 3/16" (x2) BTS (x1) Place the Pole assembly on the ground with the crimped end of the Top Pole (ALH) facing down. Position the under the bottom slots of the as shown, and step onto the Base so the Axle snaps into the slots.
  • Page 20 BACKBOARD TO POLE ASSEMBLY HARDWARE REQUIRED Hardware shown at Actual Size (x2) ABD (x4) 5/16” x 3 1/4” Hex Bolt 5/16” Washer AAC (x2) 5/16” x 1 3/4” Hex Bolt ABK (x4) 5/16” Nylock Flange Nut ADQ (x2) APN (x2) 5/16”...
  • Page 21 BACKBOARD TO POLE ASSEMBLY PARTS REQUIRED Parts shown at 10% of Actual Size ALX (x1) (x1) (x1) Right Backboard Bracket Part shown at 5% of Actual Size Part shown at 25% of Actual Size AOX (x1) Rim Support Channel (x1) Backboard TOOLS REQUIRED (x2)
  • Page 22 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 1/2” (x2) (x2) APK (x1) (Not actual size) APN (x2) Slide the 3 1/2” U-Bolt (APK) through the shown. Notch Secure the to the Top Pole (ALH) with the hardware shown.
  • Page 23 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 1/2” (x2) AAC (x2) ABK (x4) ABD (x4) Attach the Rim (ALX) and to the Pole assembly by placing the Rim Support Channel (AOX) in the recess on the underside of the Backboard with the fl...
  • Page 24 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 3/8” ADQ (x2) Bend the outward by hand and position the holes in the Backboard Brackets over the holes in . Then securely fasten the Backboard Brackets to the Backboard with the hardware shown.
  • Page 25 HARDWARE REQUIRED NO HARDWARE REQUIRED FOR THIS SECTION PARTS REQUIRED Part shown at 10% of Actual Size AKZ (x1) Part shown at Actual Size (x2) Base Plug TOOLS REQUIRED Sand (319 lb)
  • Page 26 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE (319 lb) (319 lb of sand required) a. Insert a into the in the hole closest to the Pole. b. Using a funnel, fi ll the Base with sand through the hole furthest from the Pole until the sand is just below the hole.
  • Page 27 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE a. Insert a into the in the hole closest to the Pole. b. Fill the Base with cold water through the hole furthest from the Pole until the water is just below the hole. c.
  • Page 28 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE Attach Net (AKZ) to the Rim (ALX). Note: If a replacement Net is needed, please call our Customer Service Department. Our Nets are shorter than average to reduce the risk of entanglement.

  • Page 29: Moving The System

    OPERATION OF HEIGHT ADJUSTMENT SYSTEM The basketball system may be adjusted from 7 1/2 feet to 10 feet. To Raise or Lower the Hoop: scratching surface. Do not scrape the powder coating off the Rim while adjusting the system, or you could void the product warranty and cause rusting. b.
  • Page 30 POLE CARE AND SYSTEM MAINTENANCE The life of your basketball system depends on many variables. The climate, exposure to corrosives such as salt, pesticides, or herbicides, and excessive use or misuse can all contribute to Pole failure, which may cause property damage or personal injury. Check your basketball system frequently for loose hardware, excessive wear, and signs of corrosion.
  • Page 31 NOTES...
  • Page 32 NOTES...
  • Page 33 NOTES...
  • Page 34 ® ENHANCE YOUR LIFETIME PURCHASE BY ADDING ACCESSORIES OR OTHER GREAT PRODUCTS: To purchase accessories or other Lifetime Products, visit us at: www.lifetime.com Or call: 1-800-424-3865...
  • Page 35 No cuelgue nada de la dañar el sistema y anular la garantía. www.lifetime.com #FS16400 10/12/2004...
  • Page 36 This warranty gives you specifi c legal rights, and you may also have other rights which vary from state to state. **Call or visit our Web site for Saturday hours** Please include your dated sales receipt and photographs of damaged parts. www.lifetime.com...
