- Page 1 NXG-55 / NXG-65 / NXG-70 / NXG-80 Table Stand Installation *This Installation requires a minimum of two people.
- Page 2 Lay blanket down on flat sturdy surface. Run hand over sur- face to make sure there are no sharp object or protrusions, when the television is laying down. Lay television down, viewing side down on blanket. ® All Rights Reserved. 2017 SkyVue...
- Page 3 These will be in a separate Gather the clamping nuts with springs. bag shipped with the User Manual Packet. Remove the hex head screws and washers. Set the screws and washers in a secure location. Insert spring nuts as shown in picture (2 per power strut).
- Page 4 Installation Manual - Table Swivel Stand GATHER THE FOLLOWING: STAND SWIVEL STAND ARMS Align the holes of the arms with the spring nuts the back of the television. ® All Rights Reserved. 2017 SkyVue...
- Page 5 Reinsert the Bolts with the flat washers and tighten securely into all 4 clamp nuts. Align the lower holes of the arms with the holes the swivle stand. nXG 55 / nXG 65 / nXG 70 / nXG 80 nstallatIon anual...
- Page 6 Reinsert the bolts with the flat washers and tighten securely. Place mounting plate on your tabletop. Use 4 holes indicated in the red circles to drill holes in your table top surface. Insert the fasteners that you have purchased and tighten securely. ® All Rights Reserved. 2017 SkyVue...
- Page 7 The main bolt for your SkyVue table stand is shipped with a protective coating on it. At this time please remove it. Have a friend assist you with placing the television on the stand and apply washers and nut as follows.
- Page 8 Place the provided plastic spacer on the bolt shaft. Followed by the provided Stainless Steel Washer Place the provided Stainless Steel Lock Washer Then completed with the provided Stainless Steel Nut. Be sure not to over tighten. ® All Rights Reserved. 2017 SkyVue...
- Page 9 On the back of your table stand - Insert and secure the torque screw with plastic spacer. nXG 55 / nXG 65 / nXG 70 / nXG 80 nstallatIon anual...
- Page 10 Installation Manual - Table Swivel Stand Congratulations you have successfully installed your table stand. If you have any questions call our tech support team (877)-475-9883 option 2 ® All Rights Reserved. 2017 SkyVue...
