4-IN-1 PETROL MULTI-TOOL PBK 4 A1 BENZIN-KOMBIGERÄT 4 IN 1 4-IN-1 PETROL MULTI-TOOL Originalbetriebsanleitung Translation of the original instructions Vor dem Gebrauch der Maschine sorgfältig lesen! Read carefully before using machine! IAN 331365_1907...
Page 2
Before reading, unfold both pages containing illustrations and familiarise yourself with all functions of the device. Klappen Sie vor dem Lesen die beiden Seiten mit den Abbildungen aus und machen Sie sich anschließend mit allen Funktionen des Gerätes vertraut. GB / IE / NI Translation of the original instructions Page DE / AT / CH...
4-IN-1 PETROL MULTI-TOOL PBK 4 A1 Features Engine unit PBK 4 A1-1 Introduction Safety lock-out On/Off switch Congratulations on the purchase of your new appliance. You have chosen Carrying lug a high-quality product. The operating instructions are a part of this product.
4. Pull the starter pull cord PULL Uncertainty K = 1.5 m/s Vibration on the rear handle: vibration emission value CHO KE Pull the choke lever = 7.708 m/s Uncertainty K = 1.5 m/s │ GB │ IE │ NI ■ 4 PBK 4 A1...
Page 10
Attention – petrol is highly flammable! Explosion hazard! Do not spill fuel! Turn the appliance off and disconnect the spark plug before performing any maintenance work! Attention! Risk of suffocation! GB │ IE │ NI │ 5 ■ PBK 4 A1...
Always familiarise yourself with your environment and be aware of potential dangers that you may not be able to hear because of the noise of the hedge trimmer. │ GB │ IE │ NI ■ 6 PBK 4 A1...
■ Never use the hedge trimmer with defective or missing safety devices. ■ Never grasp the hedge trimmer by the safety guards. GB │ IE │ NI │ 7 ■ PBK 4 A1...
■ Do not operate the appliance under the influence of alcohol or drugs. ■ Always hold the appliance with both hands. Your thumbs and fingers should encircle the handles. │ GB │ IE │ NI ■ 8 PBK 4 A1...
Turn the engine off and make sure that the cutting blade has come to a complete stop before performing any work on the cutting blade. GB │ IE │ NI │ 9 ■ PBK 4 A1...
You may have to loosen the saw chain to remove the blade and the saw chain (see section "Tightening and checking the saw chain"). Follow these instructions in reverse order. │ GB │ IE │ NI ■ 10 PBK 4 A1...
♦ Fit the extension attachment/boom between the engine unit and the hedge trimmer/pole pruner. The assembly is carried out in the same manner as for the attachments described previously. GB │ IE │ NI │ 11 ■ PBK 4 A1...
6 pulls, repeat steps 1 – 7 under "Starting when the engine is cold". to the supplied oil/petrol mixing canister (see "Fuel mix table"). Then shake the canister well. │ GB │ IE │ NI ■ 12 PBK 4 A1...
Wear protective goggles! Seizing Immediately turn off the engine if the cutting tool becomes blocked. Remove all grass and scrub from the appliance before restarting the appliance. GB │ IE │ NI │ 13 ■ PBK 4 A1...
9.) Cut any excess filament back to about 13 cm. This reduces the load on the engine when starting and warming up. 10.) Refit the strimmer (see section "Installing/replacing the strimmer"). │ GB │ IE │ NI ■ 14 PBK 4 A1...
If you are planning to transport the appliance, empty the fuel tank grease into the gear housing. as explained in the section "Storage". ♦ After filling the gearbox, close the lubrication hole with the screw GB │ IE │ NI │ 15 ■ PBK 4 A1...
Device ID number Current prices and information are available at www.kompernass.com NOTE ■ Replacement parts which are not listed (e.g. strimmer, cutting filament) can be ordered via our service hotline. │ GB │ IE │ NI ■ 16 PBK 4 A1...
If the defect is covered by the warranty, your product will either be re- paired or replaced by us. The repair or replacement of a product does not signify the beginning of a new warranty period. GB │ IE │ NI │ 17 ■ PBK 4 A1...
EN ISO 11806-1: 2011 EN ISO 10517: 2019 EN ISO 11680-1: 2011 EN ISO 14982:2009 EN 50581:2012 Type/appliance designation: 4-in-1 Petrol Multi-Tool PBK 4 A1 Year of manufacture: 10 - 2019 Serial number: IAN 331365_1907 Bochum, 16/10/2019 Semi Uguzlu - Quality Manager - We reserve the right to technical changes in the context of further product development.
Page 24
Treibstoff und Öl ........30 DE │ AT │ CH │ 19 ■ PBK 4 A1...
BENZIN-KOMBIGERÄT 4 IN 1 Ausstattung Motoreinheit PBK 4 A1-1 PBK 4 A1 Einschaltsperre Einleitung Ein-/ Ausschalter Trageöse Wir beglückwünschen Sie zum Kauf Ihres neuen Gerätes. Sie haben sich 4 x Befestigungsschrauben damit für ein hochwertiges Produkt entschieden. Die Betriebsanleitung ist Rundgriff...
= 4,622 m/s 4. Startseilzug ziehen PULL Unsicherheit K = 1,5 m/s Vibration am hinteren Griff: Schwingungsemissionswert CHO KE Choke-Hebel ziehen = 7,708 m/s Unsicherheit K = 1,5 m/s │ DE │ AT │ CH ■ 22 PBK 4 A1...
Page 28
Vorsicht! Verletzungsgefahr durch drehendes Schnittmesser! Hände und Füße fernhalten! Vorsicht – Benzin ist extrem leicht entzündlich! Explosionsgefahr! Keinen Kraftstoff verschütten! Vor Wartungsarbeiten Gerät abstellen und Zündkerzenstecker abziehen! Achtung! Erstickungsgefahr! DE │ AT │ CH │ 23 ■ PBK 4 A1...
Stellen Sie immer sicher, dass alle Griffe und Sicherheitseinrichtungen zu tragen. beim Gebrauch der Heckenschere angebaut sind. Versuchen Sie nie- mals, eine unvollständige Heckenschere oder eine mit nicht zulässigem Umbau zu benutzen. │ DE │ AT │ CH ■ 24 PBK 4 A1...
Achten Sie immer auf einen sicheren Stand und halten Sie jederzeit es ablegen. das Gleichgewicht. Verwenden Sie den im Lieferumfang enthaltenen Tragegurt, um das Gewicht gleichmäßig auf den Körper zu verteilen. DE │ AT │ CH │ 25 ■ PBK 4 A1...
Bevor Sie den Motor anlassen, vergewissern Sie sich, dass die Faden- spule mit keinem Hindernis in Berührung kommt. ■ Benutzen Sie das Gerät erst, wenn Sie sich mit diesem vertraut fühlen. Abb. A │ DE │ AT │ CH ■ 26 PBK 4 A1...
Benzindämpfe verflüchtigt haben. der Betriebsanleitung empfohlenen Schneidwerkzeuge oder Zubehöre ■ Aus Sicherheitsgründen sind Benzintank und Tankverschlüsse bei kann eine persönliche Verletzungsgefahr für Sie bedeuten. Beschädigung auszutauschen. DE │ AT │ CH │ 27 ■ PBK 4 A1...
Ziehen Sie an dem roten Gurtstück, falls Sie das Gerät schnell ablegen ♦ Spannen Sie jetzt die Sägekette (siehe Kapitel „Sägekette span- müssen. nen und prüfen“). ♦ Kettenradabdeckung wieder aufsetzen und Mutter leicht anziehen. │ DE │ AT │ CH ■ 28 PBK 4 A1...
(siehe Abb. 2a). ■ Den Verlängerungsvorsatz/Ausleger nicht in Kombination mit ■ Entfernen Sie die Sicherung vor Arbeitsbeginn und bringen Sie diese dem 3-Zahn-Schnittmesser-/Fadenspulenvorsatz verwenden! nach dem Arbeiten wieder an. DE │ AT │ CH │ 29 ■ PBK 4 A1...
Sie den Tragegurt abnehmen. nach 1–2 Zügen starten. Falls das Gerät nach 6 Zügen immer noch nicht startet, wiederholen Sie die Schritte 1-7 unter „Starten bei kaltem Motor”. │ DE │ AT │ CH ■ 30 PBK 4 A1...
Beschädigungen an Autos, Häusern und Fenstern führen. Schutzbrille tragen! Verklemmen Sollte das Schneidwerkzeug blockieren, stellen Sie unverzüglich den Motor ab. Befreien Sie das Gerät von Gras und Gestrüpp, bevor Sie es erneut in Betrieb nehmen. DE │ AT │ CH │ 31 ■ PBK 4 A1...
9.) Überschüssigen Faden auf etwa 13 cm zurückschneiden. Das verringert die Belastung auf den Motor während des Startens und Aufwärmens. 10.) Fadenspule wieder montieren (siehe Kapitel „Fadenspule montieren/ ersetzen“). │ DE │ AT │ CH ■ 32 PBK 4 A1...
Nach dem Befüllen des Getriebes schließen Sie die Schmieröffnung ■ Wenn Sie das Gerät transportieren möchten, entleeren Sie den Benzin- wieder mit der Schraube tank wie im Abschnitt „Lagerung“ erklärt. DE │ AT │ CH │ 33 ■ PBK 4 A1...
Artikelnummer des Gerätes ■ Ident-Nummer des Gerätes Aktuelle Preise und Infos finden Sie unter www.kompernass.com HINWEIS ■ Nicht aufgeführte Ersatzteile (wie z. B. Fadenspule, Schnittfaden) können Sie über unsere Service-Hotline bestellen. │ DE │ AT │ CH ■ 34 PBK 4 A1...
öffnen. Wenn der Defekt von unserer Garantie gedeckt ist, erhalten Sie das repa- rierte oder ein neues Produkt zurück. Mit Reparatur oder Austausch des Produkts beginnt kein neuer Garantiezeitraum. DE │ AT │ CH │ 35 ■ PBK 4 A1...
44867 BOCHUM EN ISO 11680-1: 2011 DEUTSCHLAND EN ISO 14982:2009 www.kompernass.com EN 50581:2012 Typ/Gerätebezeichnung: Benzin-Kombigerät 4 in 1 PBK 4 A1 Herstellungsjahr: 10 - 2019 Seriennummer: IAN 331365_1907 Bochum, 16.10.2019 Semi Uguzlu - Qualitätsmanager - Technische Änderungen im Sinne der Weiterentwicklung sind vorbehalten.
Page 42
KOMPERNASS HANDELS GMBH BURGSTRASSE 21 44867 BOCHUM GERMANY www.kompernass.com Last Information Update · Stand der Informationen: 11 / 2019 · Ident.-No.: PBK4A1-102019-1 IAN 331365_1907...
