Automatic Datalogging Mode
In the Automatic Datalogging mode the Model 451181 can automatically measure and
查询"451181"供应商
store 2400 readings at a programmed sample rate. To begin, press F3
WELCOME display to access LOG screens 1 and 2:

LOG SCREEN 1

F1 EXIT: Press to return to the WELCOME
screen
F2 START: Press to begin automatic Datalogging
at the pre-set sampling interval. Datalogging will
begin at the date/ time programmed in the SETUP
mode (see below).
F3 SET: Setup mode (explained in detail in the
following section).
F4 NEXT: Advances to LOG SCREEN 2
described below:
LOG SCREEN 2
F1 P-PG: Access Previous Page (previous 100
stored readings)
F2 N-PG: Access Next Page (next 100 stored
readings)
F3 PRN: Print page
F4 BACK: Return to LOG SCREEN 1
Automatic Datalogging SETUP mode
As mentioned in Softkey Group 1 above, the F3 SET selection allows the user to configure
the datalogger for the following parameters:
BEGIN: Calendar date when datalogging will
automatically begin
START: Time of day that datalogging will begin
END: Calendar date when datalogging will end
SUSPEND: Time of day that datalogging will
cease each day
RATE: Sampling interval (time between recorded
readings)
EXPECT: Total number of readings (2400)
REMAIN: Memory locations remaining
The two SETUP screens are identical but for the softkey differences (see diagrams). The
softkey functions for both SETUP screens are as follows:
EXIT: Returns to WELCOME screen.
EDIT: Select display field for editing.
VIEW: Calls up the stored readings log.
NEXT: Switches to SETUP screen 2.
START: Activates the datalogger
CLR: Erases all readings stores in the automatic
datalogger memory.
PRN: Prints the datalogger memory record
BACK: Switches to the SETUP screen 1.
LOG
0001: 07-06
V:
T:
RH:
WBT:
VOL:
P-PG N-PG
LOG SCREEN 2
0001: 07-06
V:
T:
RH:
WBT:
VOL:
EXIT START
LOG SCREEN 1
Begin:
Start:
End:
Suspend:
Rate:
Expect:
Remain:
EXIT EDIT
AUTO DATALOGGER SETUP 1
Begin:
Start:
End:
Suspend:
Rate:
Expect:
Remain:
START CLR
AUTO DATALOGGER SETUP 2
9 Model 451181 Version 3.0 07/06
from the
05:42:50
98.0FPM
82.0loF
62.7%
72.2oF
0.0CFM
PRN BACK
05:42:50
98.0FPM
82.0loF
62.7%
72.2oF
0.0CFM
SET NEXT
01-01-05
00:00:01
02-02-05
23:59:59
15 secs
2400 Points
2393 Points
VIEW NEXT
01-01-05
00:00:01
02-02-05
23:59:59
15 secs
2400 Points
2393 Points
PRN BACK
