Customizing a Memory Location Header
Using the F3 softkey in Memory screen 1, as described above, allows the user to
EDIT
查询"451181"供应商
customize the header in the currently selected memory location.
1. Use the ▲ or ▼ arrow keys to step forward and backward in the header.
2. Use the softkey to step backward
BACK
and erase characters while stepping.
3. Use the alphanumeric keypad to compose
a header. For example, press the '2' key
and a window with the characters related
to the '2' key will appear (namely,
2abcABC as shown in the diagram). Then
use the '2' key again to scroll through the
character list. When the desired character
is highlighted the meter will automatically
place that character in the header.
4. F2 is used to erase the header.
CLR
5. F4 is used to save the header.
ENTER
Viewing Stored Readings
1. From the WECLOME screen, press F2
2. Use the ▲ or ▼ arrow keys to scroll through the memory locations that contain the
stored data.
3. Press F1 to return to the WELCOME screen.
EXIT
Printing Stored Data
Proceed to the second memory screen as previously described and use F3
data record. Use the ▲ or ▼ arrow keys to select the desired data location (0- to 99) to
print.
Erasing Data
From the second memory display screen (discussed earlier), press F2
Answer when prompted to erase ALL recorded readings. Press
YES
clearing process.
01:
V:
T:
RH:
WBT:
2abcABC
VOL:
EXIT MEAS EDIT
HEADER EDITING
MEM
CLR
NO
8 Model 451181 Version 3.0 07/06
98.0FPM
82.0loF
62.7%
72.2oF
0.0CFM
NEXT
to print a
PRN
softkey.
to abort the
