To edit the fields in the datalogger display screens:
1. Use the up and down ▲ or ▼ arrow keys to scroll through the parameters.
查询"451181"供应商
2. When a parameter is highlighted, use F2
3. Use the alphanumeric keypad to edit the parameter.
4. Press F4 to save changes. Press F1
ENTER
5. Press the F1 to return to the SETUP screen.
EXIT
Recording Data in the Automatic Datalogging Mode
1. After configuring the datalogger using the SETUP screens as described above,
place the meter in position to take readings (a tripod mount is provided on the rear
of the instrument for convenience).
2. Press F3 from the WELCOME screen and then press F2 START.
LOG
3. Recording will begin on the date and time programmed at the BEGIN and START
lines in the SETUP screen.
4. The Datalogger will record everyday from the START time to the SUSPEND time.
The last day that datalogging will take place is the date programmed in the END
line.
5. When the logging begins, the screen should indicate LOGGING...
6. If the screen does not indicate logging at the programmed start time, make sure the
START key was pressed. Also check the section below entitled "Automatic
Datalogging START and END date considerations" for troubleshooting.
7. To stop logging before the programmed SUSPEND time, press F1 STOP.
8. To view the data recorded, press F4 VIEW.
9. To print data from the list, press F3 PRN. Press F2 when the PRINT? display
appears.
10. To clear (erase) the recorded data, access the LOG mode from the WELCOME
screen. Select SET and then press and hold the CLR (clear) softkey until the
display prompts for confirmation. Select YES to delete all records, or NO to abort
the clearing process.
Automatic Datalogging START and END Date Considerations
1. If the START date is set to a date before the current date, the datalogger will start
the moment the START softkey is pressed.
2. The datalogger will not start logging if the END date is set to a date before the
current date.
Software
Instructions for downloading and saving data to a PC can be found on the software disk
supplied with the meter.
to open it for editing.
EDIT
to cancel changes.
ABORT
10 Model 451181 Version 3.0 07/06
