- Page 1 Risewell User Guide 2011_Risewell Chair User Guide 3/8/2011 2:11 PM Page 1 10 Morris Drive, Unit 19 Dartmouth, NS Canada B3B 1K8 Phone: 1-800-387-0896 Fax: 1-888-355-6660 Email: info@up-lift.com Web: www.up-lift.com...
- Page 2 Risewell User Guide 2011_Risewell Chair User Guide 3/8/2011 2:11 PM Page 2 Risewell Lifting Seat Chair Enjoy your home in more places! USER GUIDE...
-
Page 3: Table Of Contents
Risewell User Guide 2011_Risewell Chair User Guide 3/8/2011 2:11 PM Page 3 Risewell Lifting Seat Chair User Guide Contents Table of Contents .................1 Welcome ....................2 Package Contents .................3 Chair Components ................4 Seat Base ....................5 Seat Assemblies ..................6 Important Safety Instructions ............7 Specifications ..................8 Assembly Instructions .................9 Operating Instructions..............11... -
Page 4: Welcome
Risewell User Guide 2011_Risewell Chair User Guide 3/8/2011 2:11 PM Page 4 Thank you for choosing the Risewell Lifting Seat Chair The Risewell has been created so you can enjoy your home in comfort and with the confidence that you can safely sit down and rise when you choose. -
Page 5: Package Contents
Risewell User Guide 2011_Risewell Chair User Guide 3/8/2011 2:11 PM Page 5 Package Contents You should have all the parts listed below with your Risewell lifting seat chair. Please check to see that all parts are included in your package. Contact your dealer if any product parts are missing or damaged. - Page 6 Risewell User Guide 2011_Risewell Chair User Guide 3/8/2011 2:11 PM Page 6 Risewell Chair Components Seat Back Removable Arm Covers Power Lever (right side only) Seat Curtain Seat Base (with Velcro) (with motor) Arm Assembly Motor Assembly (right & left) Height Adjustable Legs USER GUIDE...
-
Page 7: Seat Base
Risewell User Guide 2011_Risewell Chair User Guide 3/8/2011 2:11 PM Page 1 Seat Base (bottom view) Front Seat Base Tube Seat Base Tube Motor Control Rod The Seat Base Tubes have a Seat Base Cover to conceal Motor moving parts. In this image it has been removed from... -
Page 8: Seat Assemblies
Risewell User Guide 2011_Risewell Chair User Guide 3/8/2011 2:11 PM Page 2 Seat Assemblies Front Right Arm Assembly Power Lever Connector Left Arm Assembly Front USER GUIDE... -
Page 9: Important Safety Instructions
Use your Risewell lifting seat chair only for its intended use as described in these instructions. Do not use attachments not recommended by Uplift Technologies (the manufacturer). As with any electrical device, do not use your Risewell lifting seat chair in or near water. Never operate your Risewell lifting seat chair if it has a damaged cord or plug, or if it is not working properly, if it has been dropped or damaged, or dropped into water. -
Page 10: Specifications
Risewell User Guide 2011_Risewell Chair User Guide 3/8/2011 2:11 PM Page 4 Specifications Model: RW 01 110VAC 60Hz .5A US Patent #6,702,383 and #5,316,370. Other international patents pending. Overall Height: 39.5"/100cm* or 38"/96.5cm Width: 26”/66cm Weight: 35lb/16kg Capacity: 300lb/136kg Seat Height: 18"/46cm* or 16.5"/42cm Raised:... -
Page 11: Assembly Instructions
Risewell User Guide 2011_Risewell Chair User Guide 3/8/2011 2:11 PM Page 5 Assembly Instructions Choose a clean area to assemble your Risewell lifting seat chair. A flat, sturdy surface is required. Save the box and all packing materials. 1) Place the Left Arm Assembly on its side with the open tubes facing upward. - Page 12 Risewell User Guide 2011_Risewell Chair User Guide 3/8/2011 2:11 PM Page 6 6) Place the Connector Sleeve on the Power Lever Connector. Please refer to the picture above for correct alignment. 7) Carefully insert the Seat Base Tubes into those on the Right Arm Assembly, while also ensuring that the Connector Sleeve slides over the Motor Control Rod.
-
Page 13: Operating Instructions
Risewell User Guide 2011_Risewell Chair User Guide 3/8/2011 2:11 PM Page 7 Operating Instructions 1) After you assemble your Risewell lifting seat chair, position it in such a way that no one will trip over the power cord, and plug it in the power outlet. -
Page 14: Care And Maintenance
Risewell User Guide 2011_Risewell Chair User Guide 3/8/2011 2:11 PM Page 8 Care and Maintenance Lifting Mechanism Your Risewell lifting seat chair lifting mechanism has no user serviceable parts and does not require any routine maintenance. With proper use and care, the lift mechanism should give you years of reliable service. - Page 15 Risewell User Guide 2011_Risewell Chair User Guide 3/8/2011 2:11 PM Page 9 Care and Maintenance cont’d Stain Removal Prompt attention to stains and spots is important, as they are hard to remove if allowed to “set. ” Always proceed with stain cleaning steps in this order: 1.
-
Page 16: Troubleshooting
Risewell User Guide 2011_Risewell Chair User Guide 3/8/2011 2:11 PM Page 10 Troubleshooting What if my Risewell lifting seat chair does not operate at all when I push/pull the control switch? Check that the power cord is plugged firmly into a properly wired wall outlet. -
Page 17: Other Helpful Products
70% of your weight and travel easily wherever you go. www.SeatAssist.com Lifting Commode Uplift Commode Assist is a lifting commode that gives you independence and privacy when you need it most. Commode Assist can be used alone or over the toilet. -
Page 18: Warranty
Two-Year Limited Warranty For two (2) years from the date of purchase, Uplift will repair or replace at our option to the original purchaser any of the following parts found upon examination by an authorized representative of Uplift to be defective in material and/or workmanship: frame, motor, lift control and electrical parts.
