Denver MMP-355 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

1. Power Button
2. Band Switch
3. Function Switch
(AUX/CD/TAPE/RADIO)
4. Bass Boost Button
5. CD Mode Button
6. CD Program Button
7. CD Stop Button
8. CD Play/Pause Button
9. CD Skip/Search Forward
Button
10. CD Skip/Search Backward
Button
11. Volume Control Knob
12. Tuning Knob
13. Dial Pointer
14. CD LCD Display
15. Remote Sensor
16. Power/Standby LED Indicator
17. FM Stereo LED Indicator
18. Radio Functional Indicator
19. Tape Functional Indicator
20. CD Functional Indicator
21. Cassette Compartment
22. Aux Jack
23. Cassette Record Button
24. Cassette Play Button
25. Cassette Rewind Button
26. Cassette Fast Forward Button
27. Cassette Stop/Eject Button
28. Cassette Pause Button
29. Stereo Headphone Jack
30. Cassette Key Control Door
31. Speaker Terminal (L/R)
32. AC Power Cord
33. FM Antenna
34. CD Door
35. Speaker Box Left
36. Speaker Box Right
37. Folder Down Button "-"
38. Folder Up Button "+"
English - 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MMP-355 and is the answer not in the manual?

Questions and answers

Related Manuals for Denver MMP-355

Summary of Contents for Denver MMP-355

  • Page 1 1. Power Button 19. Tape Functional Indicator 2. Band Switch 20. CD Functional Indicator 3. Function Switch 21. Cassette Compartment (AUX/CD/TAPE/RADIO) 22. Aux Jack 4. Bass Boost Button 23. Cassette Record Button 5. CD Mode Button 24. Cassette Play Button 6.

  • Page 2: Radio Operation

    AC OPERATION Before operating, please check carefully that the voltage indicated on your set corresponds to the voltage of your local area. 1. Plug the AC POWER CORD into a standard AC outlet. 2. Press the POWER BUTTON to start the unit. POWER/STANDBY LED INDICATOR will light up to indicate unit is connected to the power source properly.

  • Page 3: Cassette Operation

    sure that your headphone has 3.5mm diameter stereo plug with an impedance of 32 ohms. During the use of a headphone, the Speakers are automatically disconnected. Cassette operation Tape Playback First of all, open the CASSETTE KEY CONTROL DOOR (30) 1.

  • Page 4: Getting Started

    4. Press the RECORD BUTTON. The PLAY BUTTON is engaged simultaneously to start recording. With the built-in Automatic Level Control (ALC), the best recording quality is automatically adjusted. Changing the volume level will not affect the recording. Release the PAUSE BUTTON to begin recording. 5.
  • Page 5 specific number of track being played. 2. For interruption while the CD is playing, press the CD PLAY/PAUSE BUTTON once. The Play Indicator “ ” will blink continuously on the LCD DISPLAY. 3. Though the sound stops, the disc will continue to spin.
  • Page 6 be shown on the LCD DISPLAY. Press the PLAY BUTTON once to start the playback. 2. To cancel the random play function, press the MODE BUTTON again, “ ” Indicator will disappear from the LCD DISPLAY. Program Mode 1. During the CD stop mode, press the PROGRAM BUTTON once. The Program Indicator “...

  • Page 7: Playing Mp3 Disc

    PLAYING MP3 DISC Getting Started Note: Should skipping of tracks occur during MP3 Disc playing, try turning the volume down. When MP3 disc is playing, do not open the CD DOOR. 1. Open the CD DOOR by pull up the CD DOOR. Put a MP3 disc into the CD compartment and close the CD DOOR.
  • Page 8 Example : To select Album # 4, track # 3. STEP – 1 : Press the FOLDER UP or DOWN BUTTON to select the Album # 4. STEP – 2 : Press the CD SKIP/SEARCH FORWARD or BACKWARD BUTTON to select the Track # 3 inside this Album # 4.
  • Page 9 Random Play Mode This feature allows the tracks on the disc to be played in a random order. 1. During the CD Stop mode, press the MODE BUTTON four times, the “ ” Indicator will show on the LCD DISPLAY. Press the PLAY/PAUSE BUTTON once to start the playback.
  • Page 10 Example : Album # 3, Track # 2. 4. To check the program you have stored after complete programming, press the PROGRAM BUTTON once during the CD Stop mode. The LCD DISPLAY will show “ ” and blink continuously. Press the FOLDER UP or DOWN BUTTON to read the Album number, then press the CD SKIP/SEARCH FORWARD or BACKWARD BUTTON to read the specific track number of said Album.

  • Page 11: Auxiliary (Aux) Mode

    AUXILIARY (AUX) MODE 1. Slide the FUNCTION SWITCH to the “AUX” position. 2. Connect the earphone socket from the Auxiliary unit (e.g. MP3 Player or MD Player) into AUX-IN-JACK (22) of this product via an Audio Line Cord (with 3.5mm plug on both ends ; Not supplied). 3.

  • Page 12: Maintenance

    3. STOP BUTTON (42) Press to stop CD play. 4. PLAY/PAUSE BUTTON (43) Press to start play or pause temporarily in CD Mode. 5. MODE BUTTON (44) Press in sequence for different play mode. Playing CD DISC : Repeat 1 Repeat All Random Play Normal Play.
  • Page 13 WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THE APPLIANCE TO RAIN OR MOISTURE. DO NOT REMOVE COVER, PILOT LAMPS SOLDERED IN PLACE. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. English - 13...
