Position the Ceiling Mount

Ceiling Tiles
WAP
Position A
* Center line of the bracket is not necessarily the center line of the WAP when installed. Please use the guide above to understand the
center line of the WAP when installing the bracket.
© 2020 Araknis Networks®
Center
Line*
Position 1
Position B
Araknis Networks Wireless Access Point
Quick Start Guide
Ceiling Mount
Center
Line*
Position 2
