Araknis Networks Wireless Access Point
Quick Start Guide
Recommended use of the Jumper Cable
You can mount your access point to the electrical box in one of two positions, shown below. These options are
provided to provide cable bend relief for cables of different lengths and thicknesses. Illustrations do not reflect
pre-install steps—please run the wire or jumper prior to connecting the access point.
Position A (810)
Double Gang
Box (not
included)
10
Single Gang
Box (not
included)
Center line
Center line
Cat 5e
NOTE: Jumper is needed when using Cat 6A in Position B.
Position B (510/810)
Cat 6A
Center Line
Center Line
Jumper
