DOREL ASIA
TODDLER BED
DA7752
DA7752M
0-65857-17412-0
0-65857-17602-5
THIS INSTRUCTION BOOKLET
CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE
DATE OF PURCHASE:
______ / ______ / ______
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, Contact our
customer service department. We will
replace the part FREE of charge.
MODEL NO:
MOCHA
UPC CODE:
MOCHA
READ AND KEEP FOR
FUTURE REFERENCE.
LOT NUMBER:
(TAKEN FROM CARTON)
Tel # : 1-800-295-1980
E-Mail: das@dorel.com
Fax #: 514-353-7819
WHITE
WHITE
NOTE:
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dorel Asia DA7752
Summary of Contents for Dorel Asia DA7752
- Page 1 DOREL ASIA MODEL NO: DA7752 WHITE DA7752M MOCHA TODDLER BED UPC CODE: 0-65857-17412-0 WHITE 0-65857-17602-5 MOCHA NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. LOT NUMBER: (TAKEN FROM CARTON) DATE OF PURCHASE: ______ / ______ / ______ DO NOT RETURN PRODUCT TO THE STORE.
