Applications:
Years
Make
2017 -Current* Hyundai
Equipment Required:
10mm
16mm
Safety
Sockets
Ratchet
Glasses
Exhaust
Tape
Soapy
Removal
Measure
Water
Pliers
DO NOT EXCEED LOWER OF TOWING VEHICLE
MANUFACTURER'S RATING OR:
Hitch Type
Weight Carrying
Weight Distributing
Installation Time: 30 min.
Models
The time listed above is the average time
for professional installers. If you do not
Ioniq
feel comfortable performing this
installation on your own or are in need of
assistance, please contact a professional
installer.
Torque
Socket
Wrench
Extensions
Utility
Knife
Marker
Max Gross Trailer Weight
2000 lb. (908 kg)
X
PART NUMBERS: 24963, 77963, CQT24963
Flat Head
Wire
Screw Driver
brush
OR
Bungee
Ratchet
Cord
Strap
Max Tongue Weight
200 lb. (90.8 kg)
X
Representative Vehicle Photo
Hitch Illustration
Advertisement
Table of Contents
Related Manuals for Draw tite 24963
Summary of Contents for Draw tite 24963
- Page 1 Installation Instructions PART NUMBERS: 24963, 77963, CQT24963 Applications: Installation Time: 30 min. Years Make Models The time listed above is the average time for professional installers. If you do not 2017 -Current* Hyundai Ioniq feel comfortable performing this installation on your own or are in need of assistance, please contact a professional installer.
- Page 2 Fastener Kit: 24963F Installation Instructions Always wear SAFETY GLASSES when installing hitch PART NUMBERS: 24963, 77963, CQT24963 ① Qty. (4) Bolt M10 X 1.25 X 30 CL10.9 Conical Washer 3/8 ② Qty. (4) Authorized Drawbar Kit: Part no. 01292006 3593...
- Page 3 1. Remove underbody panel – using a flat head screw driver and a 10mm socket, remove (5) push pin rivets and (2) hex nuts from the driver’s side panel. NOTE: Two (2) of the rivets connect the driver’s side panel to the center panel. 2.
- Page 4 3. Install hitch – Raise hitch into position, raising the passenger’s side hitch bracket above the exhaust first, then raise the driver’s side into position. Using the supplied hardware, loosely install the M10 bolts and conical toothed washers as shown. See Figure 1. NOTE: It may be necessary to clean debris from existing weldnuts in frame using a wire brush or compressed air.
