ADC Cable Assemblies CMTS Specification Sheet page 3

CMTS Cable Assemblies
MCX Crimp Connector
(4.35 mm)
.666"±.020"
number of conductors
5 5 Conductor Cable
10 10 Conductor Cable
Blade connector
M MCX
F F Connector
B BNC
L LCC
S None
Terminal connector
F F Connector
B BNC
S None
L LCC
M MCX
w w w . a d c . c o m
Remark: RoHS Compliant
0.171"
0.461" (11.7 mm)
0.657" (16.7 mm)
.344"
.156"
.094"
.594"
Recommended Strip Length
.254" ±.015"
Center Conductor To Body
• + 1 - 9 5 2 - 9 3 8 - 8 0 8 0
0.331" (8.4 mm)
0.134" (3.4 mm)
0.079" (2 mm)
Cable Stripping Dimensions
0.413" (10.5 mm)
.156"
catalog number
cBl10K -__ __ __ __ __
.666"±.020"
•
Recommended
.344"
.094"
.594"
Recommended Strip Length
length
3 3 ft.
XX XX ft.
60 60 ft.
Ship along connector
F F Connector
B BNC
S None
L LCC
M MCX
1 - 8 0 0 - 3 6 6 - 3 8 9 1
0.325"
(8.26 mm)
3
