Telesteps TSO Quick Manual

ENGINEERED CLIMBING
MADE FOR USE ON TELESTEPS SERIES E, EP, ET, ES.
ONLY TO BE USED ON THE SECTION JUST BELOW THE TOP RUNG.
OUTSIDE CORNER
French
Spanish
How to Install
1
2
3
4
How to Remove
1
2
telesteps.net
TOOL TRAY
French
Spanish
Push round black button, slide
the hook outwards you.
Push red button in the
direction of the arrow, slide
black connector piece up to
disconnect from tray.
Repeat, keeping black
connector pieces separate,
as there is corresponding
left piece and a right piece.
After removing the two black
connector pieces, place the
tray just below the top rung of
the ladder to be used.
Pushing red buttons again,
slide the two black connector
pieces back in place on correct
sides, until locked.
Slide tray upwards till the hook
can connect to the top rung.
Installation completed.
Push round black
button, disconnect
hook from top ladder
rung, and slide the tray
downward.
Push red button in the
direction of the arrow,
slide black connector
piece up to disconnect
from tray. Repeat with
second red button.
Remove tray, reinstall
black connector pieces
on tray.
INSIDE CORNER
French
Spanish
English
Push round black button, slide
the hook outwards you.
Push red button in the
direction of the arrow, slide
black connector piece up to
disconnect from tray.
Repeat, keeping black
connector pieces separate,
as there is corresponding
left piece and a right piece.
After removing the two black
connector pieces, place the
tray just below the top rung of
the ladder to be used.
Pushing red buttons again,
slide the two black connector
pieces back in place on correct
sides, until locked.
Slide tray upwards till the hook
can connect to the top rung.
Installation completed.
English
Push round black
button, disconnect
hook from top ladder rung, and
slide the tray downward.
Push red button in the direc-
tion of the arrow, slide black
connector piece up to discon-
nect from tray. Repeat with
second red button.
Remove tray, reinstall black
connector pieces on tray.
ES STEP LADDER
French
Spanish
French Spanish
Push round black button, slide
the hook outwards you.
Push red button in the
direction of the arrow, slide
black connector piece up to
disconnect from tray.
Repeat, keeping black
connector pieces separate,
as there is corresponding
left piece and a right piece.
After removing the two black
connector pieces, place the
tray just below the top rung of
the ladder to be used.
Pushing red buttons again,
slide the two black connector
pieces back in place on correct
sides, until locked.
Slide tray upwards till the hook
can connect to the top rung.
Installation completed.
French Spanish
Push round black
button, disconnect
hook from top ladder rung, and
slide the tray downward.
Push red button in the direc-
tion of the arrow, slide black
connector piece up to discon-
nect from tray. Repeat with
second red button.
Remove tray, reinstall black
connector pieces on tray.
model: TSO
FLAT WALL
French
Spanish
