Clas Ohlson ZK-6100 Quick Start Manual

Solar String Light
Art.no 36-6549 Model ZK-6100
Please read the entire instruction manual before using the product
and then save it for future reference. We reserve the right for
any errors in text or images and any necessary changes made
to technical data. In the event of technical problems or other
queries, please contact our Customer Services.

Safety

• Handle the product with care, making sure not to damage
the surface of the solar cell and ensuring that it is not
covered with dust or affected by other contaminants.
• The product must not be changed or modified in any way.
• Do not let children play with the product.
Note: The string light can also
be powered by a battery pack
(sold separately) or a mains
adaptor (not available in UK/
UAE) to enable it to be used
all year round. To do so, first
disconnect the solar cell from
the string light connection cable
and then replace it with either
a battery pack or mains adaptor.

Placement/mounting

In the ground
1. Set the switch on the back of the solar
cell to ON.
2. Attach the ground spike to the solar
cell and then push the spike into
the ground.
GREAT BRITAIN • customer service tel: 020 8247 9300 e-mail customerservice@clasohlson.co.uk internet www.clasohlson.co.uk postal 10 – 13 Market Place, Kingston Upon Thames, Surrey, KT1 1JZ
3. Adjust the angle of the solar cell
to receive as much sunlight as
possible.
4. Hang up the string light in
the desired location.
5. The string light comes on
automatically at dusk.
Fastened to a structure
1. Detach the bracket from
the solar cell.
2. Using the bracket
as a guide, mark
out the position of
the mounting holes.
3. Use an appropriate type
of screw or fastener for
the material of the structure.
Note: Ensure that there are
no electrical wires or water
pipes in the wall where you
intend to screw/drill.
4. Set the switch on the back of the solar cell to ON.
5. Screw the solar cell back onto the bracket and adjust it to
an angle to receive as much sun as possible.
6. Hang up the string light in the desired location.
7. The string light comes on automatically at dusk.

Care and maintenance

The string light and the solar cell can be cleaned by wiping
them with a damp cloth. Use only mild cleaning agents, never
solvents or corrosive chemicals.
Replacing the battery:
1. Remove the 4 screws on
the back of the solar cell.
2. Change the battery (1 × 1.2 V,
AA 600 mAh NiMH) making
sure the new battery is
inserted with the correct
polarity, see the picture.
Note: The battery must
only be replaced with
a rechargeable battery.

Responsible disposal

This symbol indicates that this product should not
be disposed of with general household waste.
This applies throughout the entire EU. In order
to prevent any harm to the environment or
health hazards caused by incorrect waste
disposal, the product must be handed in for
recycling so that the material can be disposed
of in a responsible manner. When recycling your
product, take it to your local collection facility
or contact the place of purchase. They will
ensure that the product is disposed of in
an environmentally sound manner.

Specifications

Length 940 cm
6 hours (in persistent sunlight)
Charging time
Operating time 7 hours (when fully charged)
Rechargeable battery 1 × 1.2 V, AA 600 mAh NiMH
