- Page 1 Article number: 481A71001 Mobile Stand Mix for BalanceBox®400 10° Important MAX 10° MAX 10° warnings WARNING WARNING STAY ABOVE CART MAXIMUM SLOPE DO NOT PULL DOWN WHEN MOVING before use 10 DEGREES SLOPE DOWN SLOPE Installation manual...
- Page 2 Mobile Stand Mix for BalanceBox®400 Safety Instructions What’s in the box B: 1x A: 1x C: 1x Ø75 mm / Ø3” Casters D: 2x F: 4x M10x30 E: 2x G: 4x M8x20 H: 2x M6x30 K: 4x M8...
- Page 3 Mobile Stand Mix for BalanceBox®400 Assemble the wheelbase and column To prevent scratching place a sheet of foam between the column and the table F: 4x M10x30 Make sure the top plate of each leg touches the topside of the cross bream before tightening the screws...
- Page 4 Mobile Stand Mix for BalanceBox®400 Mount the casters...
- Page 5 BalanceBox®400 Mounting BalanceBox®400* on the Mobile stand (*not included) Position 1 Adult use BalanceBox® Position 2 400* Child use Mount the BalanceBox®400* at the desired position Please follow the mounting instructions of the BalanceBox®400 G: 2x M8x20 H: 2x M6x30...
- Page 6 Article number: 481A71001 Mobile Stand Mix for BalanceBox®400 Mounting VESA bracket 481A70* on the Mobile Stand (*not included) Position 1 Adult use Position 2 Child use VESA bracket 481A70* Mount the VESA bracket 481A70 Please follow the mounting instructions of 481A70...
- Page 7 Mobile Stand Mix for BalanceBox®400 Mounting 3rd party VESA bracket on the Mobile Stand (*not included) Position 1 Adult use Position 2 Child use Party VESA bracket Mount the 3rd party VESA bracket K: M8 Please follow the mounting K: M8...
