CyberPower B704 User Manual

7-Outlet Surge Protector
B704
USER'S MANUAL
© 2017 Cyber Power Systems (USA), Inc. All rights reserved.
CONGRATULATIONS ON YOUR PURCHASE
Thank Thank you for selecting the CyberPower B704 Surge
Protector. The information contained on this package
explains the features and operation of the B704. Please take
a few moments to read this package.
FEATURES
1. ON/OFF Reset Control Switch and Circuit Breaker
Controls power to all outlets. The switch is also a 15A
breaker. When an overload occurs, it will automatically
switch o . To resume operation, ensure the overload
condition is removed and reset the surge protector by
switching the unit ON.
1
2. Surge Protected Indicator
Illuminated when the surge protection is working properly.
2
3. Seven Outlets
Seven standard outlets with safety covers.
SPECIFICATIONS
• Model Number: B704
• Outlets: 7
• Surge Protection: 1200 Joules
• Electrical Rating: 125V/15A/1875W
• UL Clamping Voltage: UL 1449 3rd/400V (L-N), 500V
(L-G), 500V (N-G)
• Maximum Peak Current: 60,000A
• 3 AC Lines Protected: L-N: 30,000A, L-G: 15,000A, N-G:
3
15,000A; (The maximum surge possible on household
wiring is 6,000 volts)
• Response Time: Less than 1 nanosecond
• Attenuation: Up to 32dB
• EMI/RFI Filtration: 150 kHz to 100 MHz
• Circuit Breaker: Resettable 15 Amp
CAUTION
TO REDUCE THE RICK OF ELECTRIC SHOCK - Use only in
dry locations and only indoors. DO NOT plug into another
relocatable power tap. DO NOT "daisy chain" surge
protectors. DO NOT use with any aquarium equipment. DO
NOT use if properly grounded outlets are not available. DO
NOT install this device if there is not at least 10 meters (30
feet) or more of wire between the electrical outlet and
electrical service panel. This device features an internal
protection that will disconnect the surge protective
component at the end of its useful life, but will maintain
power to the load – now unprotected.
TROUBLESHOOTING
If the ON/OFF is switched o , the 15A circuit breaker may
have tripped. Examine your connected equipment and
remove the device that is overloading the circuit. Then, turn
the ON/OFF switch back to RESET. If the Protected
indicator does not light, the surge protector's AC line is no
longer protected from surge. Replace the surge protector.
The surge protector may have received a power surge or
spike beyond its specified limits that overloaded the
protection circuitry and rendered it inactive. The surge
protector has protected your connected equipment but it
will not protect against future surges and spikes.
TECHNICAL SUPPORT
Please contact our Tech Support department with
installation, troubleshooting, or general product questions.
• Phone: 1-877-297-6937
• Email: tech@cpsww.com
• Hours of Operation: Monday – Friday,
1
7:00am – 6:00pm CST
2
