Adjustment Instructions
for MC5 Multifunction Calibrator
Select Quantity and Function/Port
Calibrate (Compare against a
more accurate instrument)
More Quantities to calibrate?
yes
Enable Adjustment Mode
Adjustment required?
Enter the calibration date and
Calibration Laboratory data in
the Module Settings window
For Main Firmware Version 1.90
Calibration and
Start
no
yes
no
End
Enter reference values to
adjust a Quantity in the calibrator
More Quantities to adjust?
no
Store adjustment data
Did one or
more Quantities in
no
all modules require
adjustment?
yes
Calibrating and Adjusting MC5 / 011912
yes

Advertisement

Table of Contents
loading

Related Manuals for BEAMEX MC5

Summary of Contents for BEAMEX MC5

  • Page 1 Quantity in the calibrator More Quantities to adjust? Store adjustment data Did one or Enter the calibration date and more Quantities in Calibration Laboratory data in all modules require the Module Settings window adjustment? Calibrating and Adjusting MC5 / 011912...

  • Page 2: Table Of Contents

    Calibration and Adjustment Instructions for MC5 Multifunction Calibrator For Main Firmware Version 1.90 Contents General......................3 Equipment Required for Performing the Calibration............3 Recommended Calibration Points ..................4 E module............................4 ET module ........................... 4 Pressure modules........................4 Calibrating and Adjusting the Calibrator ........... 5 Enabling and Starting the Adjustment Mode ...............

  • Page 3: General

    For Main Firmware Version 1.90 General The tolerances, linearity errors and temperature factors of the components used in the Beamex Calibrators have been carefully considered during the specification tests at the factory. All nec- essary parameters have been saved into the EEPROM memory of each measurement module.

  • Page 4: Recommended Calibration Points

    Calibration and Adjustment Instructions for MC5 Multifunction Calibrator For Main Firmware Version 1.90 Recommended Calibration Points The calibration points presented here are mostly the same as on the Calibration Certificate de- livered with the calibrator. As the heading indicates, these are recommendations, not the only suitable calibration points.

  • Page 5: Calibrating And Adjusting The Calibrator

    Calibration and Adjustment Instructions for MC5 Multifunction Calibrator For Main Firmware Version 1.90 Calibrating and Adjusting the Calibrator Calibration Since adjusting the measurement ranges affect the generation ranges (via feedback measure- Quantity Function/Port ment), all settings should first be calibrated before making any adjustments.

  • Page 6: Adjustment Of Measurement Ranges

    Calibration and Adjustment Instructions for MC5 Multifunction Calibrator For Main Firmware Version 1.90 Adjustment of Measurement Ranges Adjusting the Voltage Measurement in E Module (±50 V) Voltage Quantity: 10.00021 E: Voltage Measurement Function/Port: Source/DMM Use an accurate voltage source and connect it to the calibrator’s terminals highlighted in the adjacent picture.

  • Page 7: Adjusting The Current Measurement In E Module (±100 Ma)

    Calibration and Adjustment Instructions for MC5 Multifunction Calibrator For Main Firmware Version 1.90 Adjusting the Current Measurement in E Module (±100 mA) Current Quantity: 24.996 72 E: Current Measurement Function/Port: Source/DMM Use an accurate current source and connect to the cali- brator’s terminals highlighted in the adjacent picture.

  • Page 8: Adjusting The Resistance Measurement In Et Module (0

    Calibration and Adjustment Instructions for MC5 Multifunction Calibrator For Main Firmware Version 1.90 Adjusting the Resistance Measurement in ET Module (0 … 4000 ohm) Resistance Quantity: 70.0000 ET: Resistance Meas. Function/Port: Precision Resistor Use precision resistors and connect them to the cali- brator’s terminals highlighted in the adjacent picture.

  • Page 9: Adjusting The Pressure Measurement Of A Pressure Module

    Calibration and Adjustment Instructions for MC5 Multifunction Calibrator For Main Firmware Version 1.90 Adjusting the Pressure Measurement of a Pressure Module (Measurement Range Varies Depending on the Pressure Module) Pressure Quantity: P1…, P2…, P3…, PB…, EXT… Function/Port: (depending on the selected/available modules) 1800.0820...

  • Page 10: Adjusting The Temperature Measurement Of The Internal Reference Junction Module

    Calibration and Adjustment Instructions for MC5 Multifunction Calibrator For Main Firmware Version 1.90 Adjusting the Temperature Measurement of the Internal Reference Junction Module For obtaining best results when adjusting the Internal 0.00 °C Reference Junction Module, do the adjustment after the Temp.

  • Page 11: Adjustment Of Generation/Simulation Ranges

    Calibration and Adjustment Instructions for MC5 Multifunction Calibrator For Main Firmware Version 1.90 Adjustment of Generation/Simulation Ranges The accuracy of a generation range depends on the accuracy of the respective measurement range. Therefore the measurement range should be adjusted before trimming the generation range.

  • Page 12: Adjusting The Resistance Simulation In Et Module (0

    Calibration and Adjustment Instructions for MC5 Multifunction Calibrator For Main Firmware Version 1.90 Adjusting the Resistance Simulation in ET Module (0 … 4000 ohm) Resistance Quantity: 70.00103 ET: Resistance Sim. Function/Port: Connect an accurate Digital Multimeter to the calibra- tor’s terminals highlighted in the adjacent picture.

  • Page 13: Adjusting The Low Voltage Generation In Et Module (±500 Mv)

    Calibration and Adjustment Instructions for MC5 Multifunction Calibrator For Main Firmware Version 1.90 Adjusting the Low Voltage Generation in ET Module (±500 mV) Voltage Quantity: 449.91195 ET: Low V. Sensor Sim. Function/Port: The lowermost measurement value in the low voltage generation window is the calibrator’s own feedback...

  • Page 14: Adjusting The Voltage Generation In Et Module (±12 V)

    Calibration and Adjustment Instructions for MC5 Multifunction Calibrator For Main Firmware Version 1.90 Adjusting the Voltage Generation in ET Module (±12 V) Voltage Quantity: 11.000871 ET: Voltage Generation Function/Port: The lowermost measurement value in the voltage gen- eration window is the calibrator’s own feedback meas- urement of the generated voltage.

  • Page 15: Adjusting The Current Generation In Et Module (±25 Ma)

    Calibration and Adjustment Instructions for MC5 Multifunction Calibrator For Main Firmware Version 1.90 Adjusting the Current Generation in ET Module (±25 mA) Current Quantity: 21.999179 ET: Current Generation Function/Port: Connect an accurate Digital Multimeter to the calibra- tor’s terminals highlighted in the adjacent picture.

  • Page 16: Saving Adjustment Data

    Calibration and Adjustment Instructions for MC5 Multifunction Calibrator For Main Firmware Version 1.90 Saving Adjustment Data The adjustment data has to be saved. Otherwise they 06.11.2002 17:04 are only valid until the calibrator is shut off. SAVE ADJUSTMENTS Open the Save Adjustments window with the following Module name Cal.
