Dear user,
We have made every effort to ensure the accuracy of the contents of this manual.
Should any errors be detected, we would greatly appreciate to receive sugges-
tions to improve the quality of the contents of this manual.
For more detailed technical data about Beamex CENTRiCAL, please contact the
manufacturer.
- B
CENTR
EAMEX
ODULES
8888200 / CENTRiCALuEng / Version 1
CAL
I
AND
© Beamex 2019
BEAMEX OY AB
Ristisuonraitti 10
FIN-68600 Pietarsaari
FINLAND
Tel
Fax
E-mail:
Internet:
+358 - 10 – 5505000
+358 - 10 – 5505404
sales@beamex.com
service@beamex.com
http://www.beamex.com

Advertisement

Table of Contents
loading

Related Manuals for BEAMEX CENTRICAL

Summary of Contents for BEAMEX CENTRICAL

  • Page 1 We have made every effort to ensure the accuracy of the contents of this manual. Should any errors be detected, we would greatly appreciate to receive sugges- tions to improve the quality of the contents of this manual. For more detailed technical data about Beamex CENTRiCAL, please contact the manufacturer. © Beamex 2019...

  • Page 3: Table Of Contents

    Corner Unit, models CM and CF ..........7 Output Connector ............29 Dimensions ................8 Service ................. 30 Connecting the CENTRiCAL to the Electrical Network ..10 Selector Valve ............... 30 Pressure Supply Connections..........11 Operation ................31 Electrical Connections ............12...
  • Page 4 ® User Manual - Beamex CENTRiCAL and Supporting Modules - Contents Appendix Pressure Connections Safety Symbols Used ..............38 Environmental Specifications ..........38 Standard, Desktop, Heavy Duty & Low Workstations ..............38 Safety Precautions and Warnings ........39 General Warnings ............40 General Warnings Concerning Pressure Measurement ..............
  • Page 5 +358 - 10 - 5505404 the form when you feel like it (all items need not be answered). Then send it to Only the next page needs to be Beamex using one of the possibilities listed to the right. faxed to us. Internet: http://www.beamex.com...
  • Page 6 ____________________________________________ How helpful was the manual in using the product? (Tick a box in the percentage scale below) 10. Any ideas You want to propose to Beamex so that we can im- prove our products, operations and/or services. ____________________________________________ How well did the product suit your needs?

  • Page 7: Part 1, Introduction

    Part 1 Things discussed in this part:  About this manual.  Unpacking CENTRiCAL. NTRODUCTION...
  • Page 8 This manual presents information of Beamex CENTRiCAL's Supporting Mod- Attention! ules. The modules in the CENTRiCAL can be grouped into four main types: Before taking CENTRiCAL and its Modules into use, please read the warnings available in Part A, Appendix.

  • Page 9: General About This Manual

    General - About This Manual HERE The header of each spread in CENTRiCAL User Manual informs you of where Example of even page header: CENTRiCAL User Manual – Part 1, Introduction you are: The even page shows the part you are in and the odd page shows the main topic you are currently viewing.

  • Page 10: Unpacking And Inspection

    Part 4, Pressure Measure- ment Modules. If you have to return a module or another part of the CENTRiCAL to the factory for any reason, include a detailed description of the reason for the return. Read...

  • Page 11: Centrical

    Part 2 Things discussed in this part:  A presentation of CENTRiCAL Calibration Systems CENTR...

  • Page 12: General

    The modular construction of the system allows the user to customize the CEN- TRiCAL to practically any measurement and calibration application. The modules in the CENTRiCAL can be grouped into four main types: 1. Host modules (Calibrator modules): ...

  • Page 13: Centr Ical Mand Fmodels

    Corner CF, fixed 78 cm high table top and Instrument Panel erwise the lift will lose its programming. With a Corner Unit you are able to group two separate CENTRiCAL M or F Mod- els together to form a larger entity.

  • Page 14: Dimensions

    ® CENTRiCAL and Supporting Modules – Part 2, CENTRiCAL User Manual - Beamex IMENSIONS The dimensions for the CENTRiCAL M and F models are the same:...
  • Page 15 CENTRiCAL - Dimensions The dimensions for the Corner CM and CF models are also the same:...

  • Page 16: Connecting The Centrical To The Electrical Network

    TO THE LECTRICAL ETWORK CENTRiCAL is equipped with two power cords. One of them is an IT-socket Warning! (marked) and meant for powering computers. It is always powered even if the Before connecting the CENTRiCAL to the mains, check that power is turned off from the Instrument Panel.

  • Page 17: Pressure Supply Connections

    Vacuum pump (if ordered) is pre-installed and connected at the factory to vac- uum supply. CENTRiCAL requires clean, dry and oil free instrument air supply. Filtering of the instrument air supply is included in the base unit. The filter may be located according to user’s needs, but it needs to be part of the instrument air supply...

  • Page 18: Electrical Connections

    ® CENTRiCAL and Supporting Modules – Part 2, CENTRiCAL User Manual - Beamex LECTRICAL ONNECTIONS Electrical connections are located either in Instrument Panel or Equipment Panel. Equipment Panel is located in the Function Board at the back of the table top under flaps.
  • Page 19 Part 3 Things discussed in this part:  A presentation of CENTRiCAL Trolley movable Cali- bration System CENTR CAL T ROLLEY...
  • Page 20 TRiCAL Trolley to measurement and calibration application. The installation and uninstallation of modules is, in principle, done similarly as for CENTRiCAL M and F models. The modules in the CENTRiCAL Trolley can be grouped into four main types: 1. Host modules (Calibrator modules): ...

  • Page 21: About Centrical Trolley Centrical Trolley's Contents

     a table top (5.)  a Mobile Rack (6.)  a gas bottle holder (optional) All the modules purchased with the CENTRiCAL TR are pre-installed in the Mo- bile Rack at the factory. CENTR ONNECTING THE TO THE LECTRICAL...

  • Page 22: Pressure Supply Connections

    Vacuum pump (if ordered) is pre-installed and connected at the factory to vac- uum supply. CENTRiCAL TR requires clean, dry and oil free instrument air supply. Filtering of the instrument air supply is included in the base unit. The filter may be lo- cated according to user’s needs, but it needs to be part of the instrument air...

  • Page 23: Part 4, Pressure Measurement Modules

    Part 4 Things discussed in this part:  A presentation of Pressure Measurement Modules used in conjunction with MC6 Workstations Host Mod- ule. RESSURE EASUREMENT ODULES...

  • Page 24: General

    ® CENTRiCAL Supporting Modules – Part 4, Pressure Measurement Modules User Manual - Beamex ENERAL Pressure Measurement Modules are used in conjunction with the MC6 Work- station Host Module. Refer to MC6 Workstation User Guide on how to measure pressure using the Pressure Measurement Modules.

  • Page 25: Available Pressure Measurement Module Types And Their Measurement Ranges

    General - Available Pressure Measurement Module Types and Their Measurement Ranges VAILABLE RESSURE EASUREMENT ODULE YPES AND HEIR EASUREMENT ANGES Module Range *PB is a barometric pressure measurement module. 800 to 1200 mbar a / 11.6 to 17.4 psi a It enables absolute pressure measurement with P100m 0 to...

  • Page 26: Installing And Uninstalling Pressure Measurement Modules

    NINSTALLING RESSURE EASUREMENT ODULES To install or remove a module from your CENTRiCAL make sure both CENTRi- Warning! CAL and MC6 Workstation are shut off. Disconnect the mains cables from the Disconnect the mains cables and the pressure supply to wall outlet.

  • Page 27: Adding A Pressure Measurement Module

    ID numbers (seen in MC6 Work- station's User Interface). When you add a pressure measurement module to the CENTRiCAL, the new module should have a unique number. This is normally pre-set by Beamex. If your MC6 Workstation has problems locating the new pressure measurement module, please contact Beamex.
  • Page 28 ® CENTRiCAL Supporting Modules – Part 4, Pressure Measurement Modules User Manual - Beamex...

  • Page 29: Part 5, Pressure Output Modules

    Part 5 Things discussed in this part:  Using Pressure Output Modules RESSURE UTPUT ODULES...

  • Page 30: General

    Read carefully the warnings found in the Part A, Appendix of this ules. POC8 Pressure Output Controller Module has a separate manual deliv- manual. ered with CENTRiCAL if the Module is included in the delivery. Pressure connections are presented in Part A, Appendix of this manual.

  • Page 31: Diagrams Of Pressure Output Modules

    General - Diagrams of Pressure Output Modules IAGRAMS OF RESSURE UTPUT ODULES The pressure output modules are designed to produce very accurate pressures when calibrating pressure instruments. For pressures up to 20 bar (290 psi) an adjustable volume is used to help achieving the exact pressure. Needle valves are used in high pressure modules.
  • Page 32 ® CENTRiCAL and Supporting Modules – Part 5, Pressure Output Modules User Manual - Beamex PO8C PO8C is a variable pressure output module with an out- put range of -0.95 to 8 bar gauge (-13.7 to 116 psi). PO8C includes ...

  • Page 33: Po8C Connections

    PO8C - Connections ONNECTIONS The PO8C module is connected to the CENTRiCAL Function Board via the supply pressure hose and the vacuum hose. Usually the output of the vent valve is unconnected. Suitable hoses for output are optional and should be ordered separately.

  • Page 34: Specifications

    ® CENTRiCAL and Supporting Modules – Part 5, Pressure Output Modules User Manual - Beamex PECIFICATIONS ENERAL Feature SI Unit Imperial Width of module 528 mm 20.78" Height of module 223 mm 8.78" Total weight of module 3.25 kg 7.2 lbs Temperature range, operating.

  • Page 35: Vacuum Adjuster

    0.6 l/min 0.021 ft /min DJUSTABLE OLUME Typical pressure changes using volume's full stroke length. With a Beamex T-pressure hose connected to PO8C, MC6 one end plugged. From max. to min. volume, Final pressure Final pressure starting pressure SI Unit...

  • Page 36: Service

    ERVICE No serviceable parts inside except as noted further on. In case PO8C needs service, contact Beamex or your local distributor. Beamex's contact info is on the prepages of this manual. When disassembling PO8C, first make sure pressure and vacuum sources are disconnected.

  • Page 37: Operation

    PO8C - Operation PERATION Turn the selector valve to VENT position. Warning! High pressure is always dangerous. Read carefully the Ensure that the regulated pressure is set to zero by turning the PRESSURE AD- warnings in part Appendix of this manual. JUST knob counterclockwise.
  • Page 38 ® CENTRiCAL and Supporting Modules – Part 5, Pressure Output Modules User Manual - Beamex PO20 PO20 is a variable pressure output module with an output pressure of 0 to 20 bar gauge (0 to 290 psi). PO20 includes ...

  • Page 39: Po20 Operation

    PO20 - Operation PERATION Ensure that the regulated pressure is set to zero by turning the PRESSURE Warning! ADJUST knob counterclockwise. Also set the adjustable volume to its midpoint. High pressure is always dangerous. Read carefully the warnings in part Appendix of this manual. Connect the output of PO20 module to the instrument under test and to a suita- ble pressure measurement module.

  • Page 40: Connections

    ® CENTRiCAL and Supporting Modules – Part 5, Pressure Output Modules User Manual - Beamex ONNECTIONS The PO20 module is connected to the CENTRiCAL Function Board via the supply pressure hose. Usually the output of the vent valve is unconnected. Suitable hoses for output are optional and should be ordered separately.

  • Page 41: Po210

    PO210 - Connections PO210 PO210 are variable pressure supply modules. The fol- lowing table describes the output pressure and maxi- mum supply pressure for each module. Module Max. supply Type Output pressure pressure 0 to 210 bar gauge 230 bar PO210 (0 to 3045 psi) (3335 psi)

  • Page 42: Preparation

    ® CENTRiCAL and Supporting Modules – Part 5, Pressure Output Modules User Manual - Beamex REPARATION Before the Pressure Output Module is taken into full use, the following should be taken into consideration. All PO Modules have two pairs of valves.

  • Page 43: Connections

    B. Ball valves are not linear, so this may require some experience. ONNECTIONS The PO210 module is connected to the CENTRiCAL Function Board via the supply pressure hose. Usually the output of the vent valve is unconnected. Suitable hoses for output are optional and should be ordered separately.

  • Page 44: Maintenance Of The Pressure Output Modules

    When properly used the Pressure Output Modules should not require any regu- Installing and uninstalling a Pressure Output Mod- lar service. In case service is required, contact Beamex or your local repre- sentative. The installation and uninstallation of modules is, in...

  • Page 45: Appendix

    Appendix Things discussed in this part:  Pressure Connections  Safety Issues and Warnings  Disposal of Waste Electrical and Electronic Equipment  Briefly About Servicing CENTRiCAL and Supporting Modules  Statements and Warranty  Index PPENDIX...

  • Page 46: Pressure Connections

    The connector is delivered as shown in the upper picture to the right. The con- nector includes an adapter to make it easy to connect pressure hoses delivered by Beamex. By removing the adapter a standard 1215 Special Male -G 1/8" (in- ternal parallel) thread is revealed for connecting another type of pressure hose.
  • Page 47 For pressures higher than 250 bar Notes. Use only hand tightening when connecting Beamex pressure hoses and Beamex high pressure hoses. Use of a wrench may damage the connector. Ensure that the O-ring/seal indicated in the pictures above is intact.

  • Page 48: Safety

    ® CENTRiCAL and Supporting Modules – Appendix User Manual - Beamex AFETY YMBOLS The following symbols concerning electrical safety are used in CENTRiCAL. Alternating current, AC Direct current, DC Caution! See manual for further information NVIRONMENTAL PECIFICATIONS & L TANDARD...

  • Page 49: Safety Precautions And Warnings

    ARNINGS CENTRiCAL's Supporting Modules contains precision tools that should be used Use CENTRiCAL only if you are certain of that it can by skilled people who have read and understood this and possible adjoining man- be used safely. Safe use is no longer possible in the uals.

  • Page 50: General Warnings

    ARNINGS Note. Do not use CENTRiCAL or its Supporting Modules in any other way than as described in If your CENTRiCAL also includes an MC6 Workstation, it con- this User Manual. If this equipment is used in a manner not specified by the manufacturer, tains Lithium-Polymer (LiPo) batteries.

  • Page 51: General Warnings Concerning Pressure Measurement

    Safety - Safety Precautions and Warnings ENERAL ARNINGS ONCERNING RESSURE EASUREMENT The optional pressure T-hose is rated to the maximum pressure of 40 bar at 21°C (290 External Pressure Modules: Use only the pressure media psi at 70°F). Applying higher pressure can be hazardous. We recommend the use of the stated on the pressure module.

  • Page 52: Warnings Concerning High Pressure

    ® CENTRiCAL and Supporting Modules – Appendix User Manual - Beamex ARNINGS ONCERNING RESSURE High pressure is always dangerous. Only personnel with good experience and knowledge Check what the local regulations say about construction of high pressure liquid, air and nitrogen operations are allowed to work with the module.

  • Page 53: Disposal Of Waste Electrical And Electronic Equipment Beamex And Weee

    Disposal of Waste Electrical and Electronic Equipment - Beamex and WEEE ISPOSAL OF ASTE LECTRICAL AND LECTRONIC QUIPMENT WEEE EAMEX AND Beamex is an environmentally conscious company developing products with a view to ensure that they are easy to recycle and do not introduce hazardous ma- terials into the environment.

  • Page 54: Service

    ® CENTRiCAL and Supporting Modules – Appendix User Manual - Beamex ERVICE ENERAL A module that requires service or calibration must be carefully packed and should be accompanied with a letter or note with the following information: User’s name User’s address...

  • Page 55: Statements Disclaimer

    Statements - Disclaimer TATEMENTS ISCLAIMER Beamex has taken great care to ensure that this manual contains both accurate Beamex reserves the right to amend this manual at and comprehensive information. Notwithstanding the foregoing, the content of any time without prior notice. Furthermore, the prod- this manual is provided “as is”...

  • Page 56: Intellectual Property Rights

    RADEMARKS “Beamex”, “Beamex – A better way to calibrate as well The content of this manual is the property of Beamex Oy Ab and/or its subsidiar- ies and affiliates (referred hereinafter as Beamex). This manual and its content as the color combination of green and black as applied...

  • Page 57: Index

    Standard Accessories ....... 4 CE Conformity ......... 45 Connections ..........37 Symbols ..........38 CENTRiCAL Trolley ........ 14 Operation ........... 36 CENTRiCAL, General Presentation ... 6 Preparation ..........36 Copyrights ..........46 PO8C ............26 Connections ..........27 Trademarks ..........46 Operation ...........
