Orion MPDP User Manual

Stand unit / wall unit main frame
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
A revolutionary MPDP
Infinitely Expandable MPDP
ORION PDP CO.,LTD.
www.oriondisplay.net
Address: 257-6, Gongdan-dong, Gumi-si, Gyeongsangbuk-do, Korea
Tel : +82-2-6678-8533,
Fax: +82-2-6678-8599
A revolutionary MPDP
Infinitely Expandable MPDP
User's Manual
STAND UNIT / WALL UNIT
MAIN FRAME
Thank you for purchasing our MPDP.
Please read through this user's manual for safety before installing this product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MPDP and is the answer not in the manual?

Questions and answers

Related Manuals for Orion MPDP

Summary of Contents for Orion MPDP

  • Page 1 STAND UNIT / WALL UNIT MAIN FRAME ORION PDP CO.,LTD. www.oriondisplay.net Address: 257-6, Gongdan-dong, Gumi-si, Gyeongsangbuk-do, Korea Tel : +82-2-6678-8533, Fax: +82-2-6678-8599 Thank you for purchasing our MPDP. Please read through this user's manual for safety before installing this product.

  • Page 2: Table Of Contents

    ................1. Safety Precaution .............. 2. Installing the stand (3*3) ............ 3. Installing the MPDP ............4. Adjust the MPDP gap with the Adjuster......5. Setting MPDP ID configuration and Connection (3X3) ..WALL UNIT ................1. Safety Precaution ............

  • Page 3: Accessory

    STAND UNIT Infinitely Expandable STAND UNIT Accessory This manual describes the installation case for 3X3 sets. ¹ MAIN FRAME Accessories There are 4 different types of stand. Please select a stand type as you need. ¹ STAND.BRACKET STAND.FOOT BOLT M6*70 + NUT M6 4EA ADJUSTER M10*35 2EA BOLT M6*12 4EA MAIN.FRAME...

  • Page 4: Stand Unit

    STAND UNIT Infinitely Expandable Safety Precaution CAUTION Please install as described in this manual. Installation of this product needs 3 or more Please read and understand this manual fully before installation. ¹ people. Improper installation may cause serious injury or product Please hand over this manual to customers after installation and ask to read ¹...

  • Page 5: Installing The Stand (3*3)

    STAND UNIT Infinitely Expandable Installing the stand (3*3) Connect the Foot Stand and Stand Support together. Hook the main Frame to the lower part of the Stand. When assembling, put the Foot Stand down to prevent it from falling. Assemble the Main Frame from the lower to the upper part. Attach the Stand Support to the upper and lower parts of the Foot Stand Insert the M6*70 bolt to the Main Frame and Stand Hook.
  • Page 6 STAND UNIT Infinitely Expandable Hook the 2nd main Frame at the lower hook of the Assemble the two Main Frames. center frame. Assemble the two Main Frames at the upper and lower parts with the M6*70 bolt using the enclosed wrench and 5mm wrench. Insert the M6*70 bolt to the Main Frame and Stand Hook.
  • Page 7 STAND UNIT Infinitely Expandable Hook the 3rd Main Frame at the bottom row to the Remove the M6*70 bolt. Stand Hook. Remove the M6*70 bolts inserted at the 1st and 2nd Main Frames. Hook the Main Frame to the Stand Hook and assemble using a wrench and 5mm wrench. Make sure that the Main Frame is securely assembled when working.
  • Page 8 STAND UNIT Infinitely Expandable Assemble the Main Frame at the 2nd row. Assemble the middle Main Frame at the 2nd row. Hook the Main Frame at the 2nd row to the upper Stand Hook. Hook the Main Frame at the 2nd row to the upper Hook. Assemble the Main Frame at the 1st row and Main Frame at the 2nd Row with the M6*70 Repeat the work indicated in Step No.
  • Page 9 Fix both rows at the vertical axis as "Y-Axis Link" to the right side of the Main Frame will move from side to side. Move the vertical axis at both sides to install the MPDP. bracket for the simultaneous movement of the vertical axis.

  • Page 10: Installing The Mpdp

    Insert the PEGs in the PEG holes. Install the Guide Pins where MPDP touches. Put the set down slowly. The panels can be damaged by impact. Install the MPDP from the bottom of both sides after completing the installation at the Guide.Pin lower middle part.

  • Page 11: Adjust The Mpdp Gap With The Adjuster

    The gap of the MPDP can be fixed using the Adjuster. at the center of the vertical axis after completing the To fix the gap detected between the MPDP or when the MPDP is tilted after the installation, use the Adjuster.

  • Page 12: Setting Mpdp Id Configuration And Connection (3X3)

    This manual describes the installation for 3X3 sets. ¹ Configure MPDP ID and make connections for all the Apply following instruction according to the number of MPDP sets as you need. necessary external devices and power. Configure MPDP ID as shown in the following figure.

  • Page 13: Safety Precaution

    Installation must be done by the skilled persons Avoid weak or unstable locations. designated by sales agent or dealership. MPDP sets may fall, if the location of installation cannot withstand the weight of MPDP sets. Installation work can be very dangerous for inexperienced person.

  • Page 14: Checking The Location For Installation

    Check the positions and intervals. ¹ Check the type of wall to examine whether it can If the hole positions are not accurate, the gap between MPDP sets can withstand the weight of product. be irregular. Check the type and thickness of wall and the finish material.

  • Page 15: Installing The Wall Bracket (3 X 3)

    WALL UNIT Infinitely Expandable Installing the Wall Bracket (3 X 3) Install the Wall Bracket. Hook the Main Frame at the lower part of the Wall Bracket. Mark the location on the wall where the Bracket will be installed according to the number of Assemble the Main Frame starting from the lower to the upper part.
  • Page 16 WALL UNIT Infinitely Expandable Hook the 2nd Main Frame at the middle Wall Bracket. Assemble the two Main Frames. Insert M6*70 bolts at the Main Frame and Wall Bracket. Assemble the two Main Frames at the upper and lower parts with M6*70 bolts using a 55mm Wrench.
  • Page 17 WALL UNIT Infinitely Expandable Hook the 3rd Main Frame at the 3rd row from the Remove the M6*70 bolts. bottom to the Wall Bracket. Remove the M6*70 bolts inserted at the 1st and 2nd Main Frames. Hook the Main Frame to the Wall Bracket and assemble it with a wrench and 5mm wrench.
  • Page 18 WALL UNIT Infinitely Expandable Assemble the Main Frame at the 2nd row. Assemble the middle Main Frame at the 2nd row. Hook the Main Frame at the 1st row to the upper Hook of the Stand. Hook the Main Frame of the 2nd row to the Wall Bracket. Assemble the Main Frame at the 1st row and Main Frame at the 2nd row with M6*70 bolts.
  • Page 19 Once the supporting plate of both Main Frames at the vertical axis is removed, the M6*40 brackets move from side to side. Move the vertical axis at both sides to install the MPDP. Do not remove the supporting plate of the supporting axis.

  • Page 20: Installing The Mpdp

    Infinitely Expandable Installing the MPDP Fix both rows at the vertical axis as "Y-Axis Link" Attach the PEG and Guide Pin to the MPDP. based on the right side. Assemble the four PEGs at the back of MPDP. Install the Guide Pins where MPDP touches.
  • Page 21 Put the set down slowly. The panels can be damaged by impact. Set ID, make necessary connections and power before hang the MPDP sets on the wall. Install the MPDP from the bottom of both sides after completing the installation at the There is no room for such work after installation.

  • Page 22: Adjust The Mpdp Gap With The Adjuster

    The gap of the MPDP can be fixed using the Adjuster. at the center of the vertical axis after completing the To fix the gap detected between the MPDP or when the MPDP is tilted after the installation, use the Adjuster.

  • Page 23: Specification

    WALL UNIT Infinitely Expandable SPECIFICATION MEMO External dimension 924.5mm[W] X 526.7mm[H] X 65mm[D] 924.5 Weight 7kg.(±0.5kg)
  • Page 24 WALL UNIT MEMO...
