MAIN FRAME
ORION CO.,LTD.
www.oriondisplay.net
Address: 257-6, Gongdan-dong, Gumi-si, Gyeongsangbuk-do, Korea
Tel : +82-2-6678-8533,
Fax: +82-2-6678-8599
USER MANUAL
STAND UNIT | WALL UNIT
Thank you for purchasing our MAIN FRAME.
Please read through this user' s manual for safety before installing this product.
This product is manufactured for Multi LCD model only.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Orion STAND UNIT
Summary of Contents for Orion STAND UNIT
- Page 1 Tel : +82-2-6678-8533, Fax: +82-2-6678-8599 USER MANUAL STAND UNIT | WALL UNIT Thank you for purchasing our MAIN FRAME. Please read through this user' s manual for safety before installing this product. This product is manufactured for Multi LCD model only.
-
Page 2: Table Of Contents
MLCD Infinitely Expandable Contents ACCESSORY ................2 OPTIONAL ..................2 STAND UNIT ................3 1. Safety Precaution .................4 2. Installing the stand (3*3) ..............6 3. Installing the MLCD ..............16 4. Adjust the MLCD gap with the Adjuster..........19 5. Setting MLCD ID configuration and Connection (3X3) .......20... -
Page 3: Accessory
MLCD Infinitely Expandable www.oriondisplay.net ACCESSORY STAND UNIT MAIN FRAME Accessories This manual describes the installation case for 3X3 sets. ¿ ¿ There are 4 different types of stand. Please select a stand type as you need. ¿ STAND BRACKET STAND FOOT... -
Page 4: Safety Precaution
MLCD Infinitely Expandable www.oriondisplay.net Safety Precaution CAUTION Please install as described in this manual. Installation of this product needs 3 or more Please read and understand this manual fully before installation. people. ¿ Improper installation may cause serious injury or product Please hand over this manual to customers after installation and ask to damage. -
Page 5: Installing The Stand (3*3)
MLCD Infinitely Expandable www.oriondisplay.net Installing the stand (3*3) Connect the Foot Stand and Stand Support together. Hook the main Frame to the lower part of the Stand. • Assemble the Main Frame from the lower to the upper part. • When assembling, put the Foot Stand down to prevent it from falling. - Page 6 MLCD Infinitely Expandable www.oriondisplay.net Hook the 2nd main Frame at the lower hook of the center Assemble the two Main Frames. frame. • Assemble the two Main Frames at the upper and lower parts with the M6*70 bolt using the enclosed wrench and 5mm allen wrench.
- Page 7 MLCD Infinitely Expandable www.oriondisplay.net Hook the 3rd Main Frame at the bottom row to the Stand Remove the M6*70 bolt. Hook. • Remove the M6*70 bolts inserted at the 1st and 2nd Main Frames. • Hook the Main Frame to the Stand Hook and assemble using a wrench and 5mm allen wrench. •...
- Page 8 MLCD Infinitely Expandable www.oriondisplay.net Assemble the Main Frame at the 2nd row. Assemble the middle Main Frame at the 2nd row. • Hook the Main Frame at the 2nd row to the upper Stand Hook. • Hook the Main Frame at the 2nd row to the upper Hook. •...
- Page 9 MLCD Infinitely Expandable www.oriondisplay.net Remove the supporting plate of both Main Frames at the Fix both rows at the vertical axis as "Y-Axis Link" based vertical axis. on the right side. • Once the supporting plate of both Main Frames at the vertical axis is removed, the brackets will •...
-
Page 10: Installing The Mlcd
MLCD Infinitely Expandable www.oriondisplay.net Installing the MLCD Attach the PEG and Guide Pin to the MLCD. Install the MLCD from the lower part of the middle set. • Insert the PEGs in the PEG holes. • Assemble the four PEGs at the back of MLCD. •... -
Page 11: Adjust The Mlcd Gap With The Adjuster
MLCD Infinitely Expandable www.oriondisplay.net Adjust the MLCD gap with the Adjuster. Fix the set by pushing towards the supporting plates The gap of the MLCD can be fixed using the Adjuster. • Install the "FIX BRACKET unit" of both sets at the vertical axis by pushing towards the supporting •... -
Page 12: Setting Mlcd Id Configuration And Connection (3X3)
MLCD Infinitely Expandable www.oriondisplay.net WALL UNIT Setting MLCD ID configuration and Connection (3X3) This manual describes the installation for 3X3 sets. ¿ Configure MLCD ID and make connections for all the Apply following instruction according to the number of MLCD sets as you need. necessary external devices and power. -
Page 13: Safety Precaution
MLCD Infinitely Expandable www.oriondisplay.net Safety Precaution CAUTION Please install as described in this manual. Installation of this product needs 6 or more Please read and understand this manual fully before installation. ¿ skilled people. Improper installation may cause serious injury or product Please handover this manual to customers after installation and ask to read ¿... -
Page 14: Checking The Location For Installation
MLCD Infinitely Expandable www.oriondisplay.net Checking the location for installation. Fixing Anchor and Bolt Make sure to use specified accessory. ¿ Check the positions and intervals. ¿ Check the type of wall to examine whether it can If the hole positions are not accurate, the gap between MLCD sets can be irregular. withstand the weight of product. -
Page 15: Installing The Wall Bracket (3 X 3)
MLCD Infinitely Expandable www.oriondisplay.net Installing the Wall Bracket (3 X 3) Install the Wall Bracket. Hook the Main Frame at the lower part of the Wall Bracket. • Assemble the Main Frame starting from the lower to the upper part. •... - Page 16 MLCD Infinitely Expandable www.oriondisplay.net Hook the 2nd Main Frame at the middle Wall Bracket. Assemble the two Main Frames. • Insert M6*70 bolts at the Main Frame and Wall Bracket. • Assemble the two Main Frames at the upper and lower parts with M6*70 bolts using a 5mm allen wrench.
- Page 17 MLCD Infinitely Expandable www.oriondisplay.net Hook the 3rd Main Frame at the 3rd row from the bottom Remove the M6*70 bolts. to the Wall Bracket. • Remove the M6*70 bolts inserted at the 1st and 2nd Main Frames. • Hook the Main Frame to the Wall Bracket and assemble it with a wrench and 5mm allen wrench. •...
- Page 18 MLCD Infinitely Expandable www.oriondisplay.net Assemble the Main Frame at the 2nd row. Assemble the middle Main Frame at the 2nd row. • Hook the Main Frame at the 1st row to the upper Hook of the Stand. • Hook the Main Frame of the 2nd row to the Wall Bracket. •...
- Page 19 MLCD Infinitely Expandable www.oriondisplay.net Assemble the upper part of the 3rd row with M6*40 bolts. Remove the supporting plate of both Main Frames at the vertical axis. • Assemble the Main Frame and Wall Bracket at the upper part and the lowest row with M6*40 bolts. •...
-
Page 20: Installing The Mlcd
MLCD Infinitely Expandable www.oriondisplay.net Installing the MLCD Fix both rows at the vertical axis as "Y-Axis Link" based Attach the PEG and Guide Pin to the MLCD. on the right side. • Assemble the four PEGs at the back of MLCD. •... - Page 21 MLCD Infinitely Expandable www.oriondisplay.net Set MLCD ID and connect all the necessary external Install the MLCD from the lower part of the middle set. devices and power. • Insert the PEGs in the PEG holes. • Set ID, make necessary connections and power before hang the MLCD sets on the wall. •...
-
Page 22: Adjust The Mlcd Gap With The Adjuster
MLCD Infinitely Expandable www.oriondisplay.net Adjust the MLCD gap with the Adjuster. Fix the set by pushing towards the supporting plates at the The gap of the MLCD can be fixed using the Adjuster. center of the vertical axis after completing the installation •... -
Page 23: Specification
MLCD Infinitely Expandable www.oriondisplay.net SPECIFICATION MEMO External dimension 1026.5mm(w) x 585.7mm(h) x 65mm(d) 30.0 580.0 1026.5 65.0 weight 7.5kg(±0.5kg) - 42 - - 43 -... - Page 24 MLCD Infinitely Expandable www.oriondisplay.net MEMO MEMO - 44 - - 45 -...
