Teuco 254 Pre-Installation Card

2004.00
1/2"
with wall tap fittings
with wall tap fittings
- Hot water connection for 1/2" tap fittings
- Cold water connection for 1/2" tap fittings
- IPX5 box with PG13.5 and PG9 cable clamps
- E
LECTRICAL CONNECTION
- A
LARM SYSTEM CONNECTION
N.B. Measurements must be taken once the floors and
walls are finished.
ART. 254
Net Water Floor
(1)
Weight Content Load
Kg. lt. Kg/m 2
48 160 267
(1) - At overflow level
1/2
1/2"
BATHTUB TURNED 180°
1/2"
1/2"
INSTALLATION OF THE BUILT-IN BATHTUB
Before building the perimetre walls, it is advisable to position
the bathtub and make the necessary connections. The recess
between the wall and the external edge of the bathtub must be
of a maximum of 1.5 cm. The service and ventilation panel is
obligatory and must be positioned as indicated in the
ASSEMBLY INSTRUCTIONS.
HYDRAULIC CHARACTERISTICS
Delivery Delivery
Weight Volume
Jets N.
Kg. m 3
6
73 1,1
8
PRE-INSTALLATION CARD
STANDARD BATHTUB
with tap on rim of bathtub
with tap on rim of bathtub
Hydromassage
Water Air
Capacity l/m. Flow l/m.
300 210
400 280
ART. 254
(mm 1700 x 700)
1/2"
1/2"
1/2"
1/2"
Siphon
ELECTRICAL CHARACTERISTICS
Whirlpool
Art. V
Art.
EASY 1WEX38
230
TOP 2WTX38
2
Measurements in mm.
160
Installed
Power
Hz
kW
1
50
1,35
69
