Henden Salt and Mineral Chlorinator
HSMC15, HSMC25, HSMC35
INSTALLATION &
OWNERS MANUAL
WARNING:
Failure to follow
these instructions
and comply with all
applicable codes
may cause serious
bodily injury and/or
property damage.
The installation of
this product should
be carried out by a
person knowledgeable
in swimming
pool plumbing
requirements following
the installation
instructions provided
in this manual.
Please pass these instructions on to the operator of this equipment
IMPORTANT
Please read carefully

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HSMC15 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Henden HSMC15

Summary of Contents for Henden HSMC15

  • Page 1 Henden Salt and Mineral Chlorinator HSMC15, HSMC25, HSMC35 INSTALLATION & OWNERS MANUAL IMPORTANT Please read carefully WARNING: The installation of Failure to follow this product should these instructions be carried out by a and comply with all person knowledgeable applicable codes...

  • Page 3: Table Of Contents

    2. OPERATION OF YOUR HENDEN SALT AND MINERAL CHLORINATOR 3. CONTROL PANEL Layout 4. INITIAL START-UP 5. TYPICAL (EVERYDAY) START-UP 6. HENDEN SALT AND MINERAL CHLORINATOR FEATURES 17 Controlling chlorine output Automated timers Activating cover mode 6.4 Activating boost mode 6.5 Activating spa mode 6.6 Activating spa mode and cover mode simultaneously 26...

  • Page 4: Installation

    Henden Salt and Mineral Chlorinator Installation Manual INSTALLATION Congratulations! You are now the proud owner of a new Henden Salt and Mineral Chlorinator. Please read all information in this manual carefully before installing or operating your Henden Salt and Mineral Chlorinator.
  • Page 5 Henden Salt and Mineral Chlorinator Installation Manual IMPORTANT SAFETY INSTRUCTIONS • To minimise the risk of gas build-up in the cell housing, you must ensure there is sufficient water flow through the cell when the unit is on and producing chlorine.
  • Page 6 Henden Salt and Mineral Chlorinator Installation Manual COMMON TERMS Algae Microscopic forms of plant life which enter the pool via rain, wind and dust. There are numerous varieties – some are free floating whilst others grow on walls and in cracks and come in different colours. Some are more resistant to chemical treatment than others.

  • Page 7: Installation Instructions

    Select a convenient, well-ventilated location within one metre of the filter equipment and mount the power supply vertically onto a wall, or post at least as wide as the HSMC power supply itself. Henden recommends that the power supply shall not be located within 3 metres of the pool water.

  • Page 8: Connecting The Electrolytic Cell To The Power Supply

    Henden Salt and Mineral Chlorinator Installation Manual 1.3 Connecting the electrolytic cell to the power supply The HSMC uses a reverse polarity electrolytic cell for low maintenance operation. The HSMC power supply is fitted with a flexible lead terminated with the cell connectors built into a plastic moulding. The three in-line connectors are not “polarity sensitive”.

  • Page 9: Pre-Start Up Procedure

    • CHLORINE: For a new pool installation that has not been chlorinated, add sufficient Chlorine (liquid or granular) to achieve a reading of 3 ppm (with a suitable test kit). Alternatively, run the Henden Salt and Mineral Chlorinator continuously on BOOST MODE, for approximately 24 hours, or until a reading of 3 ppm is reached.

  • Page 10: Important Information About Your Chlorinator

    Sanitisers are a valuable piece of pool sanitising equipment and must be cared for to get the best performance and life span. There are THREE main factors that will damage your Henden Salt and Mineral Chlorinator and reduce the life of the product. Please monitor the following factors in accordance with your installation &...

  • Page 11: Mineral Chlorinator

    • The first time the Henden Salt and Mineral Chlorinator is turned on, the following screen is shown on start-up: HENDEN V1.2.7 AU 15L Figure 4.1 > This screen shows the version of software (ie v1.27 shown) and your model of HSMC (ie AU 15 shown, meaning HSMC15). HENDEN INSTALLATION & OWNERS MANUAL | 11...
  • Page 12 Henden Salt and Mineral Chlorinator Owners Manual • The display then automatically reverts to the following screen: 3. LANGUAGE 3. LANGUAGE ENGLISH ENGLISH Figure 4.2 > This screen shows the language menu and the current language setting (ie English shown);...
  • Page 13 Henden Salt and Mineral Chlorinator Owners Manual > The clock hours can be changed by pressing the menu up/down buttons to scroll to your chosen time; > Press menu/setting select once your preferred clock hour is displayed; > If a mistake is made, the setting can be changed later.
  • Page 14 Henden Salt and Mineral Chlorinator Owners Manual • The display then automatically reverts to the following screen: TIMER 1 06:00 AM Figure 4.6 > The screen shows the ON-TIME of TIMER 1: n current ON-TIME of TIMER 1 is 6:00am (example assumes 12 hour time format chosen earlier).
  • Page 15 Henden Salt and Mineral Chlorinator Owners Manual • The display then automatically reverts to the following screen: TIMER 2 05:00 PM Figure 4.8 > The screen shows the ON-TIME of TIMER 2: n current ON-TIME of TIMER 2 is 5:00pm.

  • Page 16: Typical (Everyday) Start-Up

    Henden Salt and Mineral Chlorinator Owners Manual 100% – 07:31 AM AUTO ON Figure 4.10 > This screen shows the: n current chlorine output setting (ie 100% shown); n current time setting; n current power status (ie ON shown). 5. TYPICAL (EVERYDAY) START-UP Note: Once the unit starts there is a short time delay until the cell operates to ensure the filtration system is primed with water.

  • Page 17: Henden Salt And Mineral Chlorinator Features

    Henden Salt and Mineral Chlorinator Owners Manual > This screen shows the: n current chlorine output setting (ie 100% shown); n current time setting; n current power status: AUTO ON: (ie as shown above) indicates the HSMC is currently operating within the ON-TIME of either TIMER 1, or TIMER 2;...

  • Page 18: Automated Timers

    Henden Salt and Mineral Chlorinator Owners Manual > Press the menu up/down buttons to scroll to your chosen CHLORINE OUTPUT; > The setting will change the cell duty cycle by 5% increments; > Press menu/setting select once your preferred CHLORINE OUTPUT is displayed;...
  • Page 19 Henden Salt and Mineral Chlorinator Owners Manual > The screen shows the ON-TIME of TIMER 1: n current ON-TIME of TIMER 1 is 6:00am (example assumes 12 hour time format chosen). > Initially the clock hours will be flashing; > Use the menu up/down buttons to change the time values.
  • Page 20 Henden Salt and Mineral Chlorinator Owners Manual > Using the menu up/down buttons scroll to the OFF-TIME of TIMER 1. TIMER 1 09:00 AM Figure 6.9 > The screen shows the OFF-TIME of TIMER 1: n current OFF-TIME of TIMER 1 is 9:00am (example assumes 12 hour time format chosen).

  • Page 21: Activating Cover Mode

    Henden Salt and Mineral Chlorinator Owners Manual > Using the menu up/down buttons scroll to the TIMER 2 menu. MODE 2. TIMER 2 Figure 6.12 > From this screen, press menu/setting select to enter TIMER 2 menu; > To adjust both the ON-TIME and OFF-TIME for TIMER 2, follow the same steps shown previously for TIMER 1.
  • Page 22 Henden Salt and Mineral Chlorinator Owners Manual MODE 1. TIMER 1 Figure 6.14 > Use the menu up/down buttons to scroll to the COVER MODE menu: MODE 3. COVER Figure 6.15 > From this screen, press menu/setting select to enter COVER MODE menu;...

  • Page 23: Activating Boost Mode

    Henden Salt and Mineral Chlorinator Owners Manual COVER MODE can also be triggered remotely by an automated pool cover controller. By closing the terminal block contacts on the rear of the power supply, the HSMC will remotely switch to COVER MODE.
  • Page 24 Henden Salt and Mineral Chlorinator Owners Manual > The display will show this screen: MODE 1. TIMER 1 Figure 6.19 > Press the menu up/down buttons to scroll to BOOST MODE; MODE 4. BOOST Figure 6.20 > Press menu/setting select;...

  • Page 25: Activating Spa Mode

    6.5 Activating spa mode The Henden Salt and Mineral Chlorinator is compatible with large swimming pool applications as well as much smaller spa applications. Turning on the SPA MODE reduces the cell duty cycle by 80% of its current setting.

  • Page 26: Activating Spa Mode And Cover Mode Simultaneously

    Henden Salt and Mineral Chlorinator Owners Manual MODE 1. TIMER 1 Figure 6.25 > Press the menu up/down buttons to scroll to SPA MODE; MODE 5. SPA Figure 6.26 > From this screen, press menu/setting select to enter SPA MODE menu;...

  • Page 27: Activating Winter Mode

    Henden Salt and Mineral Chlorinator Owners Manual 6.7 Activating winter mode A pool’s exposure to UV contributes significantly to the pool’s total chlorine demand ie. the amount of chlorine the pool uses. Bather load is also a significant contributor to the pool’s total chlorine demand. In winter, the pool’s chlorine demand is typically far less.

  • Page 28: Low Flow Alarm

    Henden Salt and Mineral Chlorinator Owners Manual > From this screen, press menu/setting select to enter WINTER MODE menu; > The display will show the current WINTER MODE setting (ie WINTER MODE off shown): 6. WINTER Figure 6.31 > Press menu up/down buttons to toggle between WINTER MODE on and off;...

  • Page 29: Add Salt Alarm And Low Flow Alarm

    Henden Salt and Mineral Chlorinator Owners Manual ALARM ADD SALT Figure 6.33 Once the HSMC registers a salt concentration within range (refer to recommended salt range section in the manual), the HSMC will return to normal operation. 6.10 Low salt cut-out alarm Should the salt concentration continue to be diluted, the HSMC will enter LOW SALT CUT-OUT ALARM.

  • Page 30: Overriding Clock Setting

    Henden Salt and Mineral Chlorinator Owners Manual 6.12 Overriding clock setting 70% – 09:35 AM CHLORINE OUTPUT Figure 6.35 > From the HOME screen, press and hold menu/setting select for 3 seconds. SETTINGS 1. CLOCK Figure 6.36 > Press menu/setting select;...

  • Page 31: Overriding Date Setting

    Henden Salt and Mineral Chlorinator Owners Manual > The clock AM/PM can be changed by pressing the menu up/down buttons to toggle between AM and PM; > Press menu/setting select once your preferred clock AM/PM is displayed; > If a mistake is made, the setting can be changed later;...

  • Page 32: Overriding Language Setting

    Henden Salt and Mineral Chlorinator Owners Manual 2. DATE 27 FEB 2019 Figure 6.41 > This screen shows the date format menu and the current date (ie 27 FEB 2019 shown); > Initially the date day will be flashing; > The date day can be changed by pressing the menu up/down buttons to scroll to your chosen date day;...
  • Page 33 Henden Salt and Mineral Chlorinator Owners Manual SETTINGS 1. CLOCK Figure 6.43 > Press the menu up/down buttons to scroll down to LANGUAGE menu; SETTINGS 3. LANGUAGE Figure 6.44 > Press menu/setting select; > The current LANGUAGE chosen will flash;...

  • Page 34: Overriding Time Format Setting

    Henden Salt and Mineral Chlorinator Owners Manual 6.15 Overriding time format setting 70% – 09:35 AM CHLORINE OUTPUT Figure 6.46 > From the HOME screen, press and hold menu/setting select for 3 seconds. SETTINGS 1. CLOCK Figure 6.47 > Press the menu up/down buttons to scroll down to TIME FORMAT menu;...

  • Page 35: Display Alarm History

    Henden Salt and Mineral Chlorinator Owners Manual 6.16 Display alarm history The HSMC keeps a history log for the user that registers the number of hours during which the HSMC is in alarm mode. As a reminder, the cell life expectancy will be reduced if the HSMC is run with salt concentrations outside of the recommended range.

  • Page 36: Maintenance Of Power Supply

    Henden Salt and Mineral Chlorinator Owners Manual CELL RUN TIME Figure 6.52 > Press the menu up/down buttons to toggle between cell run time and low salt time. LOW SALT TIME Figure 6.53 7. MAINTENANCE OF POWER SUPPLY The power supply requires little, or no maintenance. However, it is essential that the wall or post to which the HSMC is installed be sprayed (not the HSMC itself) periodically with a good surface type insect repellent, since penetration by insects may cause damage, which is not covered by your warranty.

  • Page 37: To Clean The Hsmc Cell

    Henden Salt and Mineral Chlorinator Owners Manual NOTE: In areas with hard water, even reverse polarity systems may require occasional manual cleaning. The life of the HSMC cell varies substantially from one installation to another due to variations in operating time, water quality and composition, system and cell maintenance.

  • Page 38: Safety Device

    If you run your Sanitiser on maximum output for 24 hours a day, or for longer periods, the cell life will be greatly reduced. It is important that the correct model HSMC has been installed on your pool. Many models are available from Henden to cope with small courtyard pools up to commercial size pools (Consult your local Reece Irrigation &...

  • Page 39: Shock" Treatment

    134m 112m NOTE: The appropriate Henden Salt and Mineral Chlorinator for your pool is dependent on the local climate, bather load of the pool and running times. Please note that the HSMC cell life can be increased with shorter running times during winter and lower output settings. Henden recommends the HSMC be run for between 6 - 8 hours a day during summer, and 4 hours during winter.

  • Page 40: General Information

    Henden Salt and Mineral Chlorinator Owners Manual 11. GENERAL INFORMATION 11.1 Pool water chemistry instructions Total Calcium Stabiliser - Recommended POOL WATER Free Chlorine Alkalinity TA Hardness Cyanuric Acid salt Levels BALANCE (ppm) (ppm) (ppm) (ppm) (ppm) 25-50ppm Concrete &...
  • Page 41 Henden Salt and Mineral Chlorinator Owners Manual NOTES HENDEN INSTALLATION & OWNERS MANUAL | 41...

  • Page 42: Henden ™ Repair Or Replacement Guarantee

    MUST provide evidence of the date of original purchase when making a claim. Henden shall not be liable for any loss of profits or any consequential, indirect or special loss, damage or injury of any kind whatsoever arising directly or indirectly from Henden products.
  • Page 43 Henden Salt and Mineral Chlorinator Owners Manual HENDEN INSTALLATION & OWNERS MANUAL | 43...
  • Page 44 P/N 403626-1...
