THUMB PIANO KIT
Assembly Instructions
E
F
WOOD PARTS
A - Hardwood frame sides (2)
B - Hardwood frame bottom
C - Hardwood frame top
D - Inner brace
E - Front (w/soundhole)
F - Back
G - Hardwood bridge
DELUXE
Updated March 2020
B
C
A
D
Musicmakers
14525 61st ST CT N
Stillwater, MN 55082
J
I
H
G
HARDWARE
H - Brass bridge rod 3/32" dia
I - Brass clamping tube 3/8" dia
J - Keys (15)
K - Rosette
not pictured:
T-nuts (2)
Machine screws (2)
Assembly instructions
Advertisement
Table of Contents
Related Manuals for Musicmakers DELUXE THUMB PIANO KIT
Summary of Contents for Musicmakers DELUXE THUMB PIANO KIT
- Page 1 J - Keys (15) D - Inner brace K - Rosette E - Front (w/soundhole) F - Back not pictured: G - Hardwood bridge T-nuts (2) Machine screws (2) Assembly instructions Musicmakers 14525 61st ST CT N Stillwater, MN 55082...
- Page 2 BEFORE YOU BEGIN _____A. Inventory and inspect all your parts carefully. If anything is 651-439-9120 missing or defective, please call us right away. _____B. It is a good idea to read through the entire assembly instructions before you start, just to get an overview of the project.
- Page 3 ____5. When the BRACE is dry, you can position the FRAME on FIG. 5 the inside of the FRONT. Notice that the narrower end of the FRAME surrounds the INNER BRACE. (fig. 4) Glue and clamp the FRAME in place, allowing at least 30 minutes for the glue to set up before continuing.
- Page 4 INSTALL THE BRIDGE FIG. 10 ____10. Check carefully the correct position for the hard- wood BRIDGE. The holes should line up with those drilled through the TOP, and the edge with the shallow groove should face the SOUNDHOLE. Trim the length of the BRIDGE, if necessary, so it does not hang over the sides of the instrument.
- Page 5 FIG. 16 ____16. Slide the KEYS under the BRASS TUBE tube, with the longest ones in the middle and the shortest ones toward each side. NOTE: One end of each key is bent downward, and that’s the end you will pluck. It should be pointing toward the sound hole.
- Page 6 HISTORY OF THE THUMB PIANO The Thumb Piano is also known as an Mbira and a Kalimba, and it originates in Africa. It is technically a “linguaphone” and is from the family of instruments known as sansas. These instruments are often made from gourds or turtle shells, with the keys (prongs or tongues) made of split cane or bamboo, or even bicycle spokes.
- Page 7 KEY OF G KEY OF C...
- Page 8 Try these songs in whichever key you tuned your instrument. You can try playing in a low range, near the center prongs, or in a higher range toward each side where the prongs are shorter. KEY OF C KEY OF G Joy to the World Joy to the World Key of G...
