Essential Lab Workstation
Hardware Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Printed in USA 03/15
Assembly Instructions
Part #256A113-02
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wenger Essential Lab Workstation
Summary of Contents for Wenger Essential Lab Workstation
- Page 1 Note: Examine the illustrations on the following pages. If you need additional information, contact Wenger Corporation using the information below. ©Wenger Corporation 2015 Printed in USA 03/15 Part #256A113-02 Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448 Questions? Call..USA: (800) 4WENGER (493-6437) • Worldwide: +1(507) 455-4100 • www.wengercorp.com...
- Page 2 Wenger Corporation. Wenger Corporation does not assume any responsibility for any errors that may appear in this manual. In no event will Wenger Corporation be liable for technical or editorial omissions made herein, nor for direct, indirect, special, incidental, or consequential damages resulting from the use or defect of this manual.
- Page 3 Required Tools · Phillips Head Screwdriver · 3/16” Allen Wrench (supplied) · 3/8” & 7/16” Open-End Wrenches, or Sockets · 5/32” Allen Wrench (supplied) Hardware Parts List X003497 X001503 X003283 X003311 #10 x 1.75 #10-16 x 3/4 1/4-20 x .590 1/4-20 Pan Head Screw Pan Head Screw...
- Page 4 Assembly 1. Lay the Desktop flat on the ground with the pilot holes facing up. Be careful not to scratch the Desktop surface! 2. Attach the Legs to the bottom of the Desktop in the orientation shown below. a. If including the Optional Spacer Tubes (#13), attach the Legs and Spacer Tubes to the Desktop pilot holes using six #10-16 x 1.75 Pan Head Screws (#1).
- Page 5 Assembly (continued) 3. Attach the Leg Cross Member to both Legs using two 1/4-20 x .590 Machine Screws (#3) and 1/4-20 Cap Nuts (#5). Leg Cross Member 1/4-20 x .590 1/4-20 Machine Screws Cap Nuts (#3) (#4) 4. Attach the Stiffener to the rear Desktop pilot holes using eight #10-16 x 3/4 Pan Head Screws (#2) as shown.
- Page 6 Assembly (continued) 5. With the glides facing the inside, attach both Keyboard Brackets to the Desktop pilot holes using six #10-16 x 3/4 Pan Head Screws (#2) in each as shown. #10 x 3/4 Pan Head Screws (#2) Left Hand Keyboard Bracket Right Hand...
- Page 7 Assembly (continued) 7. If attaching the optional Power Strip: a. Fit the heads of two #10-32 x 3/8 Pan Head Screws (#8) into the slots in the Power Strip and fit the screws through the holes in the Stiffner as shown. b.
- Page 8 Assembly (continued) 9. Turn the Assembly over. If attaching the optional CPU Holder: a. Assemble the CPU Holder according to the manufacturer’s instructions. b. Attach the CPU Holder to the nut inserts in the Inserts Desktop with four 1/4-20 x 5/8 Truss Head Screws (#5) as shown.
