Contents
Important User Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Required Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Hardware Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Workstation Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Visit the Music Lab Workstations web page at www.wengercorp.com.
Note: Please read and understand these instructions before starting the assembly.
Note: If you need additional information, contact Wenger Corporation using the information below.
©Wenger Corporation 2018
Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448
Questions? Call.....USA: (800) 4WENGER (493-6437) • Worldwide: +1-507-455-4100 • wengercorp.com
Select Lab Adjustable Height
Basic Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Mobile Version Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Non-Mobile Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Final Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Optional Rackmount Shelf Assembly . . . . . . . . . . . . . . . . . . . . . . 23
Printed in USA 2018-07
Assembly Instructions
Workstation
Mobile version is shown.
Also available without casters.
Part #225D098-02
Advertisement
Table of Contents
Related Manuals for Wenger Select Lab
Summary of Contents for Wenger Select Lab
-
Page 1: Table Of Contents
Visit the Music Lab Workstations web page at www.wengercorp.com. Note: Please read and understand these instructions before starting the assembly. Note: If you need additional information, contact Wenger Corporation using the information below. ©Wenger Corporation 2018 Printed in USA 2018-07 Part #225D098-02 Wenger Corporation, 555 Park Drive, P.O. -
Page 2: Important User Information
Wenger Corporation. Wenger Corporation does not assume any responsibility for any errors that may appear in these instructions. In no event will Wenger Corporation be liable for technical or editorial omissions made herein, nor for direct, indirect, special, incidental, or consequential damages resulting from the use or defect of these instructions. -
Page 3: Safety Precautions
• WARNING means that failure to follow the instruction may result in serious injury or death. • CAUTION means that failure to follow the instruction may result in serious injury or damage to property. Read all of these safety instructions before assembling the Select Lab Adjustable Height Workstation. CAUTION CAUTION... -
Page 4: Hardware Parts List
Hardware Parts List 250A508._ X003583 X003706 X000045 X002540 100A444 7 x 50mm 2-3/8” Grommet 2” 5-Knuckle #8 x 5/8” 8 x 25mm Corner Particle Board Screw Hinge Pan Head Screw Wood Dowel Bracket (color matched paint) X003074 X000824 X003600 X001503 X002971 Flush Mount #8-18 x 3/8”... -
Page 5: Workstation Components
Workstation Components Item Description Item Description Shelf Wiring Panel Standard Swivel Caster Front Wiring Panel Adjustable Keyboard Bracket Back Panel Bottom Fixed Shelf Left Side Panel Wiring Access Door Right Side Panel Stiffener Desktop Pullout Panel Left Side Support Weldment Headphone Mount Right Side Support Weldment Plain Channel*... -
Page 6: Basic Assembly
Basic Assembly The following assembly procedure shows the Mobile Version of the Adjustable Height Workstation, the procedure is the same for the Non-Mobile Version unless otherwise noted. 1. Connect the Shelf Wiring Panel (29) and Front Wiring Panel (30) together using six Wood Dowels (5) and five Black 7 x 50mm Particle Board Screws (28). - Page 7 Basic Assembly (continued) 3. Attach four Wiring Clamps (9) to the Back Panel using four #10-16 x 3/4” Sheet Metal Screws (10). #10-16 x 3/4” Sheet Metal Screw (10) Wiring Clamp 4. Attach two sets of 5-Knuckle Hinges (3) to the Back Panel using two #6 x 3/4”...
-
Page 8: Left Side Panel
Basic Assembly (continued) 5. Insert eight color matched 1/4-20 Cap Nuts (23) into the outside surface of both the Left Side Panel (32) and Right Side Panel (33). Dowel holes are in the The outside of the Side Panels do not have dowel holes. inside of the Side Panels. -
Page 9: Right Side Panel
Basic Assembly (continued) 8. Attach the Front Wiring Panel and Back Panel Assembly to the Right Side Panel (33) using three Wood Dowels (5) and five 7 x 50mm Particle Board Screws (1). Leave the Particle Board Screws loose until after Step #9. Right Side Panel (33) Wood Dowel 7 x 50mm Particle Board Screw These two screws may need to be removed to complete Step #9. -
Page 10: Left Side Support Weldment
Basic Assembly (continued) 11. Attach the Left Side Panel to the Desktop, Back Panel and Front Wiring Panel using six Wood Dowels (5) and eight 7 x 50mm Particle Board Screws (1). Left Side Panel (32) Wood Dowel 7 x 50mm Particle Board Screw 12. -
Page 11: Mobile Version Assembly
Mobile Version Assembly The following assembly procedure shows how to assemble the Mobile Version of the Adjustable Height Workstation. For Non-Mobile Version Assembly, go to page 14. 1. Attach the Left Side Support Weldment (35) and the Right Side Support Weldment (36) to the Back Panel using three Right Side #8 x 5/8”... -
Page 12: Mobile Leg Tube
Mobile Version Assembly (continued) 4. Attach the Left and Right Side Support Weldments to the Nut Inserts in the Side Panels using eight 1/4-20 x 0.708” Machine Screws (25) in each. 1/4-20 x 0.708 Machine Screw (25) 5. Attach six Wiring Clamps (9) to the Back Panel using six #10-16 x 3/4”... -
Page 13: Swivel Caster With Brake
Mobile Version Assembly (continued) 7. Insert one Adjustable Leg Assembly with the Plug end at the top through the bottom of all four of the Side Support Weldment slots. Adjustable Leg Assembly 3.75 Dia x 2.50 8. Attach the two Swivel Casters with Brakes to Clevis Pin the front of the Workstation and two (15) -
Page 14: Non-Mobile Assembly
Non-Mobile Version Assembly The following assembly procedure shows how to assemble the Non-Mobile Version of the Adjustable Height Workstation. For Mobile Version Assembly, go to page 11. 1. Attach six Wiring Clamps (9) to the Back Panel using six #10-16 x 3/4” Sheet Metal Screws (10). #10-16 x 3/4”... - Page 15 Non-Mobile Version Assembly (continued) 3. Using a mallet, tap a 1-1/4” Plug (14) into both open ends of all four Mobile Leg Tubes (47). Non-Mobile Leg Tube (47) 1-1/2” Plug (14) 4. Insert one Adjustable Leg Assembly with the Plug end at the top through the bottom of all four of the 3.75 Dia x 2.50 Plain Channel slots.
-
Page 16: Final Assembly
Final Assembly The following assembly procedure shows the Mobile Version of the Adjustable Height Workstation, the procedure is the same for the Non-Mobile Version unless otherwise noted. 1. Attach seven Corner Brackets (6) to the Desktop, Side Panels and Front Wiring Panel using #8 x 5/8”... - Page 17 Final Assembly (continued) 3. This step is for the Mobile Version Only, does not apply to the Non-Mobile Version: Insert four Black 1/4-20 Cap Nuts (24) into pilot holes in the the top of the Bottom Fixed Shelf (41). Black 1/4-20 Cap Nut (24)
- Page 18 Final Assembly (continued) 5. Attach the Bottom Fixed Shelf (41). Mobile Version Instruction (Non-Mobile Version on the following page): a. Keep the narrower side of the Bottom Shelf at the same side as the Keyboard Brackets (this leaves room for a computer tower on the wider side of the shelf). b. With the Cap Nuts facing up, tip the Shelf to fit onto the bottom lips of the Side Support Weldments.
- Page 19 Final Assembly (continued) 5. Attach the Bottom Fixed Shelf (41). Non-Mobile Version Instruction (Mobile Version on the previous page): a. Tip the Assembly onto the Back Panel. Narrower side b. Keep the narrower side of the Bottom Shelf at the same side as the Keyboard Brackets (this leaves room for a computer tower on the wider side of the shelf).
- Page 20 Final Assembly (continued) 6. Attach the Flush Mount Handle (7) to the longer Wiring Access Door (42) using two #8-18 x 3/8” Sheet Metal Screws (8). #8-18 x 3/8” Sheet Metal Screw Flush Mount Handle Wiring Access Door (42) 7. Attach a Wiring Access Door to each set of Hinges in the Back Panel using two #6 x 3/4”...
- Page 21 Final Assembly (continued) 8. Attach a Stiffener (43) to the bottom on the back side of the Pullout Panel (44) using three #8 x 5/8” Sheet Metal Screws (17). #8 x 5/8” Sheet Metal Screw (17) Holes can be used to secure keyboard cables with the included 4”Nylon Ties (27). Front side has edge banding Pullout Panel (44) Back side is unfinished...
- Page 22 Final Assembly (continued) 11. Fit the back of both Drawer Glides into the slots of the Front Wiring Panel. Attach the Pullout Drawer to the Adjustable Keyboard Brackets using Fit Drawer Glides one 1/4-20 x 1/2” Carriage Bolt (11), into slots 1/4 x 47/64”...
-
Page 23: Optional Rackmount Shelf Assembly
Optional Rackmount Shelf Assembly If installing the Optional Rackmount Shelf Assembly, the smaller Wiring Access Door and Hinges must be removed. 1. Clip the Cage Nuts into the front of each individual Rackmount Shelf. Rackmount Shelf Unit 10-32 x 3/4” Truss Screws are included to secure electronic components into the Rackmount. - Page 24 Optional Rackmount Shelf Assembly (continued) 4. Attach two 5-Knuckle Hinges to the top Rackmount Shelf #8-32 x 1/2” using two #8-32 x 1/2” Flat Head Screws and Flat Head Screw two #8-32 Nylon Lock Nuts in each. Push-In 5-Knuckle Bumper Be sure that the screws are seated flush with Hinge the hinges.
