St. Ives 135cm/150cm storage bed
Thank you for purchasing St. Ives storage bed. Please read the instructions carefully before use
to ensure safe and satisfactory operation of this product.
Pre-assembly preparation
Please ensure instructions are read in full before attempting to assemble this product
Necessary Tools
Stock number: 80343003 · 80343103 · 80343004 · 80343104
Advertisement
Related Manuals for John Lewis St. Ives 80343003
Summary of Contents for John Lewis St. Ives 80343003
- Page 1 St. Ives 135cm/150cm storage bed Stock number: 80343003 · 80343103 · 80343004 · 80343104 Thank you for purchasing St. Ives storage bed. Please read the instructions carefully before use to ensure safe and satisfactory operation of this product. Pre-assembly preparation Please ensure instructions are read in full before attempting to assemble this product Necessary Tools...
- Page 2 Please check the pack contents before attempting to assemble this product. A full checklist of components is given in this leaflet. If any components are missing, please contact the number on the front of this assembly instruction. HEAVY, TAKE This product is it should be assembled as near as possible to the point of use.
- Page 4 Step by step assembly instructions Step One All Bolts (A) must be screwed into pre drilled cams of Head end (01) and Foot end (04) as shown (8 into the head end and 8 into the foot end) and leave minimum 4 mm gap. Step Two Attach the sides (02) and (03) to the Head end (01) and Foot end (04) as shown, push the sides firmly sideward.
- Page 5 Step Three Take the centre support (08) and attach the middle feet (10) as shown per diagram below. Step Four Fittings (B) must be screwed into the pre drilled cams of the middle support (05). Attach the center support rail (08) onto the support brackets, push firmly downwards to secure in place.
- Page 6 Step Five On each of the bed slats (H) put the slat holder (I) and then fit the slat into the predrilled holes on the bedframe, as shown in the diagram. Repeat this step with the other 40 slats. Please fit the side supports (09) in the middle of each side of the bed.
- Page 7 Put the handles (F) on the drawer front and tighten them with screws (E). Step Seven Please ensure the bedframe is square from corner to corner. Gently push the drawers in their position.
-
Page 8: Care And Maintenance
Care and Maintenance St. Ives range is a timeless painted bedroom range in white with brushed metal knob handles and grey with solid aok flat tops and brushed metal knob handles. Each piece has been carefully constructed to ensure it will give you years of pleasure. natural characteristics of oak may include small cracks, knots, blemishes and grain pattern variations wich all add to the natural charm and beauty of this furniture product. - Page 9 It is recommended that before moving heavy objects to a new location they are completely disassembled to avoid personal injury or damage to the furniture. Please be careful to retain all fittings when doing this. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE John Lewis Partnership 171 Victoria Street London SW1E 5NN www.johnlewis.com...
