Simpli Home WyndenHall Brooklyn + max ARTISAN AXCART44-SG Assembly Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SIMP
I
HOME
®
I
L I F E B Y D E S I G N
ARTISAN / HOLDEN / STRATFORD
DRESSER
MODEL # AXCART44-SG
1/19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WyndenHall Brooklyn + max ARTISAN AXCART44-SG and is the answer not in the manual?

Questions and answers

Related Manuals for Simpli Home WyndenHall Brooklyn + max ARTISAN AXCART44-SG

Summary of Contents for Simpli Home WyndenHall Brooklyn + max ARTISAN AXCART44-SG

  • Page 1 SIMP HOME ® L I F E B Y D E S I G N ARTISAN / HOLDEN / STRATFORD DRESSER MODEL # AXCART44-SG 1/19...
  • Page 2 SIMP HOME ® L I F E B Y D E S I G N Questions, problems, assembly help, missing parts? No need to return the product, we will gladly help and ship your replacement parts free of charge Please call Customer Service at 1-866-518-0120 ext. 262 Monday to Friday between 9 am –...

  • Page 3: Safety Information

    IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. SAFETY INFORMATION CAUTION: Injuries and damage can occur from furniture tip over if product is not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint provided with the product.

  • Page 4: Care And Maintenance

    IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. CARE and MAINTENANCE Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls, and in doing so it swells and shrinks.

  • Page 5: Pre-Assembly Information

    PRE-ASSEMBLY INFORMATION MODEL # AXCART44-SG PARTS DESCRIPTION TOP SHELF BOTTOM FRAME QTY 1 QTY 1 QTY 2 LEFT SIDE RIGHT SIDE DIVIDER QTY 1 QTY 1 QTY 1 BACK PANEL BACK PANEL BOTTOM SUPPORT LEG QTY 1 QTY 1 QTY 1 NEED HELP? For help with assembly or if you are missing a part, Please call customer service at 1-866-518-0120 ext.
  • Page 6 PRE-ASSEMBLY INFORMATION MODEL # AXCART44-SG PARTS DESCRIPTION RIGHT FLIP DOWN DOOR LEFT FLIP DOWN DOOR LEFT DRAWER FRONT QTY 1 QTY 1 QTY 2 RIGHT DRAWER FRONT LEFT DRAWER SIDE RIGHT DRAWER SIDE QTY 2 QTY 4 QTY 4 PLASTIC JOINING STRIP DRAWER BACK DRAWER BOTTOM QTY 4...

  • Page 7: Hardware Description

    PRE-ASSEMBLY INFORMATION MODEL # AXCART44-SG HARDWARE DESCRIPTION ALLEN KEY BOLT ALLEN KEY SCREW CAM LOCK PIN HANDLE CAM LOCK M6 X 30 mm M6 X 30 mm M4 X 27 mm QTY 24 QTY 22 QTY 16 SETS QTY 6 SETS PHILLIPS SCREW ROUND HEAD PHILLIPS SCREW...
  • Page 8 COMPONENTS – KEY DIAGRAM MODEL # AXCART44-SG 8/19...
  • Page 9 ASSEMBLY MODEL # AXCART44-SG STEP 1 1. Attach 4 Cam Lock Pins 3 to pre-drilled holes at back of Left Drawer Front KL . 2. Align Cam Lock Pins with guide holes and attach Drawer Sides LL , LR . 3.
  • Page 10 ASSEMBLY MODEL # AXCART44-SG STEP 3 1. Align Drawer Back M with Drawer Bottom N and press firmly into slot . 2. Attach Drawer Back using 2 Allen Key Screws 2 through guide holes on each Side LL , LR . 3.
  • Page 11 ASSEMBLY MODEL # AXCART44-SG STEP 5 1. Attach Bottom Frame B to Divider F using 3 Allen Key Screws 2 . Tighten Screws 2 by Allen Key 5 . 2. Attach Top Shelfs C to Divider F using 6 Allen Key Bolts 1 ( 3 Bolts / each Shelf ). 3.
  • Page 12 ASSEMBLY MODEL # AXCART44-SG STEP 6 NOTE: The screwdriver is not included in the hardware pack. 1. Attach Top Shelfs C and Bottom Frame B to Sides D & Side E using 12 Allen Key Bolts 1 through indicated holes ( 6 Bolts / each Side ). 2.
  • Page 13 ASSEMBLY MODEL # AXCART44-SG STEP 7 1. Attach Top A to Side E and Side D using 6 Allen Key Bolts 1 ( 3 Bolts / each part ). Use Allen Key 5 to tighten bolts. 2. Attach Top A to Divider F using 3 Allen Key Screws 1 . 3.
  • Page 14 ASSEMBLY MODEL # AXCART44-SG STEP 8 1. Attach the upper Back Panel G to back frame by using Phillips Screws 6 . Only 1 top row of screws ( 7 Screws ) to be screwed in advance. 2. Insert the lower Back Panel H into the slot of Plastic Joining Strip O . 3.
  • Page 15 ASSEMBLY MODEL # AXCART44-SG STEP 9 NOTE: The screwdriver is not included in the hardware pack. 1. Attach hinges on Top Shelf C to Flip Down Door JL , JR using Phillips Screw 10 . 2. Attach Latch 9 to Divider F and Flip Down Door JL , JR using Phillip Screws 8 into pre-drilled holes.
  • Page 16 ASSEMBLY MODEL # AXCART44-SG STEP 10 1. Insert assembled drawers into glides on assembled dresser. 16/19...
  • Page 17 FURNITURE TIP OVER RESTRAINT ASSEMBLY WARNING Serious or fatal crushing injuries can occur from furniture tip-over. If the furniture tip over restraint kit is not in the box, please contact our customer service department in order to obtain another kit before using the furniture. STEP 11 NOTE: The screwdriver is not included in the hardware pack.
  • Page 18 FURNITURE TIP OVER RESTRAINT ASSEMBLY Furniture Tip Over Restraint Instructions: Attach one of the mounting brackets securely to the back edge of the furniture. Use the shorter screw. Determine where furniture is to be placed and mark location on the wall for mounting bracket screw hole approximately 2 inches below the bracket mounted to the furniture.

  • Page 19: Warranty

    L I F E B Y D E S I G N WARRANTY Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max product. These products have been made to demanding, high-quality standards and are guaranteed for domestic use against manufacturing faults for a period of 12 months from the date of purchase.

This manual is also suitable for:

Wyndenhall brooklyn + max holden axcart44-sgWyndenhall brooklyn + max stratford axcart44-sg
