Figure 13. 24-Hour Performance History Line Data Screen; Figure 14. Performance Data Definitions Screen - ADTRAN T200 H2TU-R Installation And Maintenance Manual

At each 15-minute interval, the performance
information is transferred to the 15-minute
performance data register. This unit stores
performance data in 15-minute increments for the last
24-hour period. At each 24-hour interval, the
performance data is transferred into the 24-hour
performance data registers. This unit stores up to 31
days of 24-hour interval data.
CIRCUIT ID:
1. Definitions
2. Reset Data
3. 15 Min Data
4. 24 Hr Data
5. Line Data
6. Path Data
7. H2TUC DSX-1
8. H2TUC LOOP
9. H2TUR LOOP
10. H2TUR DS1

Figure 13. 24-Hour Performance History Line Data Screen

CIRCUIT ID:
H2TUC, H2TUR, and H2R LOOP Related:
ES-L Errored Seconds
SES-L Severely Errored Seconds
UAS-L Unavailable Seconds
DS1 and DSX-1 Line Related:
ES-L Errored Seconds
SES-L Severely Errored Seconds
UAS-L Unavailable Seconds
CV-L Code Violation Count
NOTE: Reverse video indicates invalid data due to a terminal restart (or power
cycle), a data register reset, or a system date or time change.
N. Next
P. Previous
12
Press ESC to return to previous menu
Menu 24 Hour H2TUC DSX-1 Performance Data
ES-L
00000 00000 00000 0000000
12/31 ----- ----- ----- -------
12/30 ----- ----- ----- -------
12/29 ----- ----- ----- -------
12/28 ----- ----- ----- -------
12/27 ----- ----- ----- -------
12/26 ----- ----- ----- -------
12/25 ----- ----- ----- -------
12/24 ----- ----- ----- -------
12/23 ----- ----- ----- -------
12/22 ----- ----- ----- -------
Selection:
Press ESC to return to previous menu
Performance Data Definitions
Selection:

Figure 14. Performance Data Definitions Screen

Section 61222026L7-5, Issue 2
The user is prompted to select a module and interface
to view the corresponding performance data. Line (L)
and Path (P) can be viewed.
Abbreviations used in the Performance History
screens are defined in Data Definition Screens, see
Figure 14 and Figure 15.
SES-L UAS-L CV-L
___
-7->| C |
| |<-8---9->|
<---|___|
HDSL2 Framing
CRC>=1 or LOSW>=1
CRC>=50 or LOSW>=1
>10 cont. SES-Ls
Superframe and Extended Superframe
(BPV+EXZ)>=1 or LOS>= 1
(BPV+EXZ)>=1544 or LOS>=1
>10 cont. SES-Ls
(BPV+EXZ) count
01/01/00 00:08:22
___
| R |---->
|
|___|<-10-
01/01/00 00:54:35
61222026L7-5B
